Figure 8. Wiring the WCI to a UC400 or a UC600
Figure 9. Wiring the WCI to a BCI-I
Attach jumper at BI1
to enable wireless
communication.
Jumper
24
VAC
Figure 10. Wiring the WCI to a BCI-R
BAS-SVX40A-EN
LINK
BI 1 BI 2 BI 3
BCI-I
Gray = LINK -
Blue = LINK+
Black = Ground
Red = 24 Vdc
IM C
+ 24
VDC
IMC
UC
WCI
VDC
LINK IMC
Mounting and Wiring the WCI
Gray = LINK -
Blue = LINK +
Black = Ground
Red = 24 Vdc
IM C
+ 24
BCI-R Board
Gray = IMC–
Blue = IMC+
Slide switch to IMC
RTRM
Black = Ground
Red = 24 Vac
