Controls

7

Swivel out the roller-presser

.04

● In the raised position the roller-presser

1 can be swivelled out by gently pulling

downwards.

1

Fig. 7 - 04

7

Knee lever

.05

● Operate knee lever 1 to raise the roller

presser.

1

Fig. 7 - 05

17
