Controls
7
Keyboard on machine head
.03
● The machine as a keyboard with 4 keys to activate different functions.
● When the keys 1 – 4 are operated on the standard version, the functions listed below are
Key 1:
Key 2:
Key 3:
Key 4:
16
Fig. 7 - 03
carried out.
Reverse sewing or intermediate backtacks during the seam (Standard)
Needle position change / Half stitch
In setting 203, this button can be allocated to the following functions:
1 = Half stitch, 2 = Needle position change, 3 = Knee switch
Needle position change / Single stitch
In setting 204 this button can be allocated to the following functions:
1 = Single stitch, 2 = Needle position change, 3 = Knee switch
EMERGENCY key
Needle rises without thread trimming, thread tension is released, roller presser is
raised and the motor start inhibitor is activated. If the key is operated again, the
motor start inhibitor is deactivated.
1
2
3
4
