- Page 3 R 8290 Needle Reverse feed control Thread take-up lever Automatic needle threader Light switch Thread retainer stud Needle thread tension Drop feed control Zigzag finger-tip control Sewlight Needle plate Bobbin winder Stitch width dial Transverse rotary hook Stop motion knob Needle position lever Bed slide Stitch length dial...
- Page 4 IL— R 8292 Needle set screw Face cover Balance wheel Bed plate Presser bar lifter Collapsible spool pins Space for built-in motor Sewing foot thumb screw Top cover Double receptacle for speed control and Sewing foot Needle threader control power cords...
- Page 6 Knee Control lightly knee Press the right against the knee control lever. The harder you press, the faster the machine will run. &&ct2icat Lnotmatton Push plug 1 into receptacle 2, and plug 3 at other end of card into the wall outlet. Foot Control The foot or knee control is permanently Place the foot control under the...
- Page 8 R 7999 i qa9 $eivin if you want to sew a few wide zigzag stitches while the machine is set for straight stitching (A on 0), merely press down the finger-tip control. When the lever is released, the machine resumes straight slitching automatically. To sew longer zigzag seams, turn dial A to desired stitch width (indicated by numbers 1 to 4).
-
Page 10: Bobbin Winder
Pass end of thread through slot in bobbin, from inside. Set bobbin on bobbin winder spindle so that key at bose of spindle enters slot in bobbin. Press in lever i. Hold end of thread and start machine. Having wound a few turns, break off end of thread and continue winding. - Page 12 It is best to tilt machine bock when inserting bobbin case the first time. After you hove become more practiced, you will manage without tilting it. Move bed slide all the way to the left. Make sure the needle is still at its highest point. With the thumb and forefinger of left hand, lift latch k and turn bobbin case until slot at end of latch points up (see arrow).
- Page 15 and lead thread end through both Place spooi of thread on spool pin thread retainer openings 4 (see illustration opposite). Lead thread clockwise around tension and pull it between any two of the tension discs Bring take.up lever 6 as high as it will go and pass thread from right to left through one of the holes at its end.
- Page 19 — —...
- Page 20 -;.-‘- ——...
-
Page 22: Drop Feed Control
,i41ahLne ‘Eee The machine feed is dropped for darning, hoop embroidery and button sew ing. To lower feed below the needle plate, turn drop feed control v clock wise. Fabric will cease feeding. When control v is turned to the right as far as it will go, feeding of the fabric resumes automatically when you start sewing. - Page 26 R 8031...
-
Page 28: Bed Slide
‘7ôti 1. Machine Skips Stitches Cause: Remedy: Needle incorrectly inserted. Push needle up as far as it will go and be sure that the long groove faces toward you, and flat side of shank away from you. The correct needle system is stamped on bed slide. Wrong needle. - Page 34 51378 A —2 — R7169 R 5925 51378 B— 4.
- Page 35 —...
- Page 36 1278 Inserting Patches • A—2 to 4 (optional) B— Machine Setting: Large holes con be patched quickly. The following method may be used for jersey fabrics. Cut patch so that its grain wilt match the rest of the fabric. Place the patch over the damaged area.
- Page 38 R 7163 6I21 Applique Work — to 3 Machine Setting: A—1 Pin or bosie applique on fabric and overcast edges. Appliques also can be attached with a satin stitch or any embroidery design. R 7429 R 7167...
- Page 42 ——...
-
Page 46: Face Cover
Darning Machine Setting: A—O B— Prepare your machine for darning as follows: Remove presser foot and drop machine feed. Use feed cover plate No. 41 251 to increase tautness of fabric in hoops and permit free movement. To fasten the feed cover plate to the machine, slip its finger into the hole of the needle plate, as illustrated, turn, and fasten in position with bed slide (see illustration below). -
Page 48: Sewing Foot
Attach cord stitcher and sew outlines of monogram. Watch that seams do not overlap at joints of letters. To raise monogram, insert.o filler thread. Ask your Pfaff dealer to show you P FAF F’s Ornamentograph, the ingeniously designed monogram and ornamental stitch attachment. You will marvel at its versatility and delight in its countless creative possibilities. - Page 50 Increase the bobbin thread tension slightly for cording. Pfaff recommends you fill your cording so it keeps its shape in the laundry. Filler cord thickness depends on cording size you want. To sew filled cording, use the two cording plates with cord ducts.
- Page 52 The Transverse Spool Holder To ensure thot the thread will unwind evenly from a cross-wound spool, use the transverse spool holder which is part of the standord equipment of your ma chine. over the vertical spool pin, To attach the spool holder, slip position spring the bent portion of the spring pointing toward you.
