7

Controls

7
On/off switch / Sewing lamp switch
.01
1
Fig. 7 - 01
7

Pedal

.02
-1
Fig. 7 - 02
2
3
0
+1
-2
(option)
● To switch the control system of the
machine on or off, turn main switch 1.
● Switch the sewing lamp, which is inte-
grated in the machine head, on or off by
operating switch 2.
● Switch 3 regulates the brightness of the
sewing lamp.
● With the on/off switch on
0
= Machine stop
+1 = Sew
- 1 = Raise roller presser
- 2 = Trim thread
Controls
