O P E R A T I N G M A N U A L 4 x BEEP & RED LED BLINKING MOVE TO FRESH AIR! FIBARO CO SENSOR FGCD-001 CONTENTS v1.1 #1: Description and features #7: Battery #2: Basic activation #8: Associations... -
Page 2: Important Safety Information
General information about the FIBARO System FIBARO is a wireless smart home automation system, based on the Z-Wave protocol. All of available devices can be controlled through a computer (PC or Mac), smartphone or tablet. Z-Wave devices (non- battery powered) are not only receivers, but can also repeat the signal, increasing the Z-Wave network’s range. -
Page 3: 1: Description And Features
#1: Description and features FIBARO CO Sensor is an ultra-light, compact, battery-powered carbon monoxide detector, designed to be placed on a wall. Its high sensitivity allows to detect the presence of the carbon monoxide (CO) gas at the early stage in order to prevent carbon monoxide poisoning. -
Page 4: 2: Basic Activation
3. Remove the paper strip protecting may be used in coop- the battery. eration with Z-Wave Controller (eg. FIBARO Home Center) as a part of smart home system. 4. Proper powering up will be con- firmed with a short beep. -
Page 5: 3: Adding/Removing The Device
#3: Adding/removing the device Adding (Inclusion) - Z-Wave device learning mode, allowing to add NOTE the device to existing Z-Wave network. When powered, the To add the device: device will indicate 1. Place the device within direct range of the Z-Wave controller. Z-Wave status with colour of LED: 2. -
Page 6: 4: Physical Installation
#4: Physical installation READ BEFORE INSTALLATION AND HEED ALL THE WARNINGS! The device should be installed below the ceiling level. • • The device should be installed on the wall, at least 30 cm (1 ft) away from the corners. •... -
Page 7: 5: Operating The Device
#5: Operating the device Menu allows to perform Z-Wave network actions. In order to use the menu: 1. Press and hold the button for 3 seconds 2. you should hear a short signal while the LED diode blinks white. 3. Release the button. 4. -
Page 8: 6: Visual Indications & Acoustic Signals
#6: Visual indications & acoustic signals Indications and signals: The CO Sensor is equipped with a LED diode and a buzzer, signalling menu position and status of the device. Device status indications: What What you see What it means What to do you hear Detected pres- 1. -
Page 9: Fibaro Co Sensor
#7: Battery FIBARO CO Sensor can be powered with CR123A (included) battery. CAUTION Estimated battery life with device on default settings is 3 years (tested with Panasonic Industrial Lithium). using batteries other than specified may result in explosion. Checking battery level:... - Page 10 #8: Associations Association (linking devices) - direct control of other devices within NOTE the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter Association ensures or scene (may be controlled only through a Z-Wave controller). direct transfer control commands between devices, is The device provides the association of six groups: performed without...
- Page 11 Notification report: The device uses Notification Command Class to report different events to 1st association group (Lifeline). Notification Type Triggering Event 1. Carbon monoxide detected, unknown location CO Alarm 2. Carbon monoxide test 3. Replacement required Heat Alarm Overheat detected, unknown location Home Security Tampering, product covering removed Power Management Replace battery soon...
-
Page 12: 9: Advanced Parameters
#9: Advanced parameters The CO Sensor allows to customize its operation to user’s needs. The NOTE settings are available in the FIBARO interface as simple options that may be chosen by selecting the appropriate box. Entering invalid value of parameter will re-... - Page 13 Available settings: 0 - all actions disabled NOTE 1 - tampering (opened casing) Parameter 3 values may be combined, e.g. 2 - exceeding the temperature 1+2+4=7 means that 4 - lack of Z-Wave range all actions will be ac- Default setting: Parameter size: 1 [byte] tive.
- Page 14 12. Value of BASIC OFF command sent to 2nd association group NOTE This parameter defines the value of BASIC OFF command sent to de- Setting parameters vices in 2nd association group after the CO Alarm cancellation. 11-12 to appropriate value will result in: Available settings: 0-99 or 255 0 - turning associated 0 (turn off )
- Page 15 19. Value of BASIC OFF command sent to 4th association group NOTE This parameter defines the value of BASIC OFF command sent to devices in Setting parameter 19 4th association group after falling below the CO level set in parameter 17. to appropriate value will result in: Available settings: 0-99 or 255...
-
Page 16: 10: Specifications
#10: Specifications Power supply: CR123A 3.0V battery (included) CAUTION using batteries other Battery life: 3 years on default settings than specified may (tested with Panasonic Industrial Lithium) result in explosion. Dispose of properly, Lifespan under typical 8 years observing environ- conditions: mental protection... - Page 17 Directive 2014/53/Eu. The full text of the Eu declaration of conformity is available at the following internet address: www.manuals.fibaro.com WEEE Directive Compliance Device labelled with this symbol should not be disposed with other household wastes.
