FIBARO FGFS-101-ZW5 Instruction Manual

FIBARO FGFS-101-ZW5 Instruction Manual

Flood sensor

Advertisement

Quick Links

INSTRUCTION MANUAL
FLOOD SENSOR
FIBARO SYSTEM

Advertisement

loading
Need help?

Need help?

Do you have a question about the FGFS-101-ZW5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FIBARO FGFS-101-ZW5

  • Page 1 INSTRUCTION MANUAL FLOOD SENSOR FIBARO SYSTEM...
  • Page 2: Technical Support

    Should you need any assistance in connecting or configuring your Home Center, please use our guides and technical presentations which can be found on our website: http://www.fibaro.com/us/support For all other questions email our support team: support-usa@fibaro.com Note: The Flood Sensor works with most Z-Wave Controllers such as Home Center 2, Home Center Lite, SmartThings, Vera, Nexia, and HomeSeer.
  • Page 3: Functional Features

    Functional features Water sensor Temperature sensor Siren and light Tilt sensor alarm...
  • Page 4 Download FIBARO app for smartphone...
  • Page 5: Start The Device

    Start the device STEP 1 Twist and open the casing. STEP 2 Take off the casing.
  • Page 6 Start the device STEP 3 Remove the battery blocker “I’m ready”. STEP 4 Check if the battery You will hear a beep while is placed correctly. LED diode blinks red.
  • Page 7 Your Flood Sensor is ready to be added to the Home Center. Flood Sensor must be in range of the Home Center because it requires a direct communication with the controller.
  • Page 8 Start inclusion mode STEP 5 Start your FIBARO application. Go to Settings.
  • Page 9 Start inclusion mode STEP 6 Press “add device”. STEP 7 Press “Next”.
  • Page 10 Inclusion mode has been launched Still need help? Watch the Inclusion video...
  • Page 11 Add your device STEP 8 Quickly, triple click the button in order to add your device to the system.
  • Page 12 Processing your con igurations...
  • Page 13 Wake up the device Sometimes waking up the device is not required so it will be omitted automatically. STEP 9 Quickly, triple click the button in order to wake up the device. Still need help? Watch the Wake Up the Device video...
  • Page 14 The device has been added STEP 10 Name the device and assign it to the room.
  • Page 15 Network range test It is recommended to check if the device’s destination is in range of your Home Center. STEP 11 Hold the button for about 10-15 seconds until LED diode blinks violet. STEP 12 Release the button, and press it again. The quality of the network range will be indicated by different...
  • Page 16 Network range test – quality indicator Direct Routed Limited No signal! The device communication communication communication will not work correctly! STEP 13 Press the button in order to leave testing mode. Still need help? Watch the Network Range Test video...
  • Page 17 Close the casing STEP 14 Close and twist the cover.
  • Page 18: Installation

    During the installation it is recommended to wake up the device. 3. A built-in temperature sensor lets FIBARO Flood Sensor should be installed you monitor e.g. frozen pipes. in all spaces, where’s the risk of flood: • In the bathroom, •...
  • Page 19 Adding a probe If the sensor cannot fit the space which is in danger of flooding you can install a wired probe* that will get to difficult to access spaces. Install the probe here *The probe is not included in the Flood Sensor set.
  • Page 20 www.fibaro.com...
