KNOW YOUR PRODUCT

ROTARY TOOL

1 Collet Nut
2 Shaft Collar
3 Spindle Lock Button
4 Accessible Brushes
1 2 3

ACCESSORIES

9 Flexible Shaft
10 Locking Chuck
11 Spindle Lock
12 Fitting Collar
9 10 11 12
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
5 Variable Speed Dial
6 On/off Switch
7 Hanging Ring
8 Power Cord
4 5 6 7
13 Spindle Lock Key
14 Rotary Bits x 106
15 Spanner
13 14 15
SETUP & PREPARATION

1. CHANGING ACCESSORIES

WARNING!
fROM ThE pOWER SUppLY bEfORE pERfORMING ANY
Of ThE fOLLOWING OpERATIONS.
1 Press and hold the spindle
lock button.
8
3 Select a suitable collet for
the accessory to be used
and insert. Then cover
with collet nut.
4 Lightly tighten the collet nut so
that it stays in place.
5 Insert shaft of accessory
into the collet.
6 Tighten collet nut using spindle
lock and spanner.
ENSURE ThE TOOL IS dISCONNECTEd
2 Unscrew the collet nut and
remove completely.
