Ozito RTK-2100 Instruction Manual

Ozito RTK-2100 Instruction Manual

Rotary tool kit
Hide thumbs Also See for RTK-2100:
Table of Contents

Advertisement

Quick Links

Download this manual
ROTARY
TOOL KIT
120W
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
230-240V ~ 50Hz
Power:
120W
No Load Speed:
10,000 - 32,000/min
Max Collet Size:
ø 3.2mm
Flexible Shaft Length: 1.0m
Kit Weight:
1.65kg
ozito.com.au
WHAT'S IN THE BOX
Rotary Tool
Rotary Bits x 218
Flexible Shaft
Spanner
RTK-2100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTK-2100 and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito RTK-2100

Summary of Contents for Ozito RTK-2100

  • Page 1 Rotary Tool TOOL KIT 120W Rotary Bits x 218 INSTRUCTION MANUAL SPECIFICATIONS Voltage: 230-240V ~ 50Hz Power: 120W No Load Speed: 10,000 - 32,000/min Max Collet Size: ø 3.2mm Flexible Shaft Flexible Shaft Length: 1.0m Kit Weight: 1.65kg ozito.com.au Spanner RTK-2100...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION ROTARY TOOL 1. CHANGING ACCESSORIES 1 Collet Nut 5 On/off Switch 2 Shaft Collar 6 Variable Speed Dial Ensure the tool is disconnected from the power supply before performing any of the following operations. 3 Spindle Lock Button 7 Hanging Ring 4 Accessible Brushes...

  • Page 3: Flexible Shaft

    2. CHANGING ACCESSORIES CONT. 3. FLEXIBLE SHAFT Locating a cutting/sanding disc 1. Remove the shaft collar. 2. Loosen the collet nut. 1. Remove the screw from the end of the disc holder. 3. Raise the handle end of the flexible 3.

  • Page 4: Operation

    5. Gently apply the tip of the accessory to the workpiece. CAUTION: PLACING EXCESSIVE LOAD ON THE ROTARY TOOL WHILE IT IS RUNNING AT LOW SPEEDS MAY CAUSE IT TO OVERHEAT AND THE MOTOR TO FAIL. RTK-2100...

  • Page 5: Accessory Guide

    ACCESSORY GUIDE TYPE QTY/ SIZES INCLUDED APPLICATIONS ASSEMBLY 1.5mm x1 Used to fit a variety of accessories, with Collet 2.3mm x2 different shank sizes, to your rotary tool. 3.2mm x1 A mandrel is a shank to which polishing Mandrel accessories, cutting wheels and sanding wheels can be fitted.
  • Page 6 ACCESSORY GUIDE TYPE QTY/ SIZES INCLUDED APPLICATIONS GRINDING ACCESSORIES Use to refine the edges of the other Dressing Stone grinding accessories after they have been used. Suitable for various kinds of grinding and Aluminium Oxide Wheels x6 sharpening applications. Available in a Grinding Stones &...

  • Page 7: Maintenance

    • If the replacement of the supply cord is necessary, this has to be done by the manufacturer or his agent in order to avoid a safety hazard. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.

  • Page 8: Spare Parts

    Tool: 120W Rotary Tool SPARE PARTS Model No. RTK-2100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Carbon Brush Assembly (pair) SPRTK2100-06 Collet &...
  • Page 9 GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and finger on the switch or energising power tools that have the switch on invites accidents.

  • Page 10: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0813...
