Technical Data - Ozito ROTARY TOOL SET Original Instructions Manual

Items supplied

Technical data

Please check that the article is complete as Operating voltage of the drive unit: .......................
specified in the scope of delivery. If parts are .................................................230-240 V~ 50 Hz
missing, please contact our service center or the
Power input: .............................................. 170 W
sales outlet where you made your purchase at
Idle speed n : ........................... 8,000-35,000/min
the latest within 5 working days after purchasing 0
Clamping range: ................................. 1.5-3.2 mm
the product and upon presentation of a valid bill
Protection class: ...........................................II /
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
Danger!
instructions.
• Sound and vibration
Open the packaging and take out the equip-
Sound and vibration values were measured in
ment with care.
• accordance with EN 60745.
Remove the packaging material and any
packaging and/or transportation braces (if
L sound pressure level ........................ 73 dB(A)
available).
pA
•
K uncertainty ............................................. 3 dB
Check to see if all items are supplied.
pA
•
Inspect the equipment and accessories for L sound power level .......................... 84 dB(A)
WA
transport damage.
K uncertainty ............................................. 3 dB
•
WA
If possible, please keep the packaging until
the end of the guarantee period.
Wear ear-muffs.
The impact of noise can cause damage to hea-
Danger!
ring.
The equipment and packaging material are
not toys. Do not let children play with plastic
Total vibration values (vector sum of three direc-
bags, foils or small parts. There is a danger of
tions) determined in accordance with EN 60745.
swallowing or suffocating!
Vibration emission value a
Proper use
K uncertainty = 1.5 m/s
The Grinding and Engraving Set is designed to
perform drilling, grinding, deburring, polishing,
The specified vibration value was established in
engraving, cutting, milling and cleaning jobs
accordance with a standardized testing method.
on wood, metal and plastic in model-making,
It may change according to how the electric
workshop and household applications. Use the
equipment is used and may exceed the specified
tool and accessories only for those applications
value in exceptional circumstances.
described.
The specified vibration value can be used to
The equipment is to be used only for its prescri-
compare the equipment with other electric power
bed purpose. Any other use is deemed to be a
tools.
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
The specified vibration value can be used for initi-
ries of any kind caused as a result of this.
al assessment of a harmful effect.
Please note that our equipment has not been de-
Keep the noise emissions and vibrations to a
signed for use in commercial, trade or industrial
minimum.
applications. Our warranty will be voided if the •
Only use appliances which are in perfect wor-
machine is used in commercial, trade or industrial
king order.
businesses or for equivalent purposes. •
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever
necessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in ac-
cordance with instructions, certain residual
risks cannot be rules out. The following ha-
zards may arise in connection with the equip-
ment's construction and layout:
&
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protecti-
on is used.
3. Health damage caused by hand-arm vibra-
tions if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
≤ 3.74 m/s
2
h
2
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment. The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
