CraftUnique CraftBot Plus Service Manual page 8

3.2 Exploded view - Extruder
14
13
ITEM NO. ORDER NUMBER
1 sm.001.004
2 ma.001.017
3 ma.001.016
4 be.000.007
5 bm.000.022
6 by.001.003
7 ma.001.001
8 sm.001.035
9 sm.000.001
10 sm.001.005
11 sm.001.006
13 sc.002.008
14 sc.002.017
15 bm.001.001
16 bm.000.025
17 sc.002.004
18 sc.002.003
19 el.000.001
20 sp.000.004
21 sc.002.012
22 ma.001.007
23 ma.000.003
24 sc.002.013
25 bm.000.014
Service manual for CraftBot Plus and CraftBot 2 models
Page: 8 / 32
10 7 8 9
11
22
15
25 16
PART NAME
Extruder base
Block X2
Block X2
Stepper motor 17hs3001-20b 1
Linear bearing - LM8UU
Washer M3L2 plastic
Washer M3L2 metal
Extruder swing
Extruder excenter
Extruder front
Extruder top
Screw DIN912 M3L10
Screw DIN912 M5L10
Filament bearing
Filament drive gear v2
Screw DIN913 M3L4
Screw DIN7380 M4L8
FFC PCB v1.1
FFC gripper
Screw DIN912 M3L6
PTFE top holder
Belt holder
Screw DIN912 M3L8
Extruder spring
18 1
4
2
QTY.
1
1
1
4
1
3
1
1
1
1
4
2
1
1
5
4
1
1
2
1
2
4
1
Copyright Craftunique ltd. All rights reserved.
Version V1.0
21
20
19
3
5
23
24
17
