CraftUnique CraftBot Plus Service Manual page 10

3.4 Exploded view - Z screw
Service manual for CraftBot Plus and CraftBot 2 models
Page: 10 / 32
1
2
3
4
5
6
ITEM NO. ORDER NUMBER PART NAME
1 bm.001.010
2 bm.000.024
3 ma.001.011
4 ma.001.010
5 ma.001.012
6 ma.001.013
7 sc.002.011
8 sc.002.004
Copyright Craftunique ltd. All rights reserved.
Version V1.0
Z screw bush
Pulley GT2 6mm 20 teeth
Z holder
Z coupler
TR8x2 Z nut
Z screw CBP TR8x2
Screw DIN912 M3L4
Screw DIN913 M3L4
QTY.
2
1
1
1
1
1
1
1
