CraftUnique CraftBot Plus Service Manual page 18

Part name
Timing belt 132cm
Belt holder
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Cable_ FFC cable 0.5-44-620A
sm29_ffcleszorító FFC gripper
Screw - Nut M3 - DIN934_M3
Xcross metal FFC
... Sticker - Keep hands clear
Screw - Allen key M3L1 6 - DIN912_M3L1 6
PCB - Pr3dator v2.0 FFC
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Cable tie - 12cm
Fan assy
... fan_holder painted
... Screw - Allen key M3L1 0 - DIN912_M3L1 0
... Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
... Connector - power 3P 2.54 male fan
... Shrink tube 1.2 1cm
... Fan - 12V 40mm
... Shrink tube 2.4 1cm
... Shrink tube 3.0 1cm
Push on foot - Rubber POF-12664
Plexiglass CBP
Screw - Allen key M3L8 - DIN912_M3L8 Nickel plated
Screw - Nut M3 - DIN934_M3 1
Top conver CBP - Grey - assy
... Top cover CBP - Grey - painted
... Led strip 35cm white w/connector
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Build plate assy
... Knurled nut - White
... Kapton sheet CBP - 0.1 5mm 250mm x 21 0mm
Sticker - serial - small
Sticker - serial - big
Back cover - CBP/2 - FFC - assy - Grey
... Back cover - CBP/2 - FFC - Grey
... Fan - 1 2V 80mm
... Screw - Fan 5L1 5
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Battery - CR2032
Screw - Allen key M3L8 - DIN912_M3L8 Nickel plated
Screw - Set screw M3L4 - DIN913_M3L4 flat
Please note: only the items marked with asterisk can be ordered.
Service manual for CraftBot Plus and CraftBot 2 models
Page: 18 / 32
Copyright Craftunique ltd. All rights reserved.
Version V1.0
Order number Quantity
by.001.004 *
ma.000.003 *
sc.002.012
be.001.003 *
sp.000.004
sc.003.002
pr.001.047
pt.000.003
sc.002.010
el.000.009 *
sc.002.012
bm.000.021
pr.002.013 *
sp.000.001
sc.002.008
sc.002.012
be.001.001
pr.000.007
be.000.014
pr.000.008
pr.000.009
bm.000.019 *
ma.001.018 *
sc.002.013
sc.003.002
pr.001.030
sp.001.006
el.001.001 *
sc.002.012
pr.001.037 *
bm.000.026
by.001.007
pt.000.005
pt.000.006
pr.001.039
sp.001.016
be.000.015
sc.002.021
sc.002.012
be.000.001
sc.002.013
sc.002.004
2
2
4
1
1
2
1
1
4
1
4
2
1
1
6
2
1
1
3
1
1
4
2
6
6
1
1
1
6
1
2
1
2
1
1
1
1
4
6
1
3
1
