4. Spare parts overview

Part name
Frame - FFC - Grey
Bearing - flanged - belt_F624Z
Screw - Washer M4 - DIN125_M4_200HV
Screw - Allen key M4L1 6 - DIN912_M4L1 6 Nickel plated
Power supply - 24V - assy
... Power supply - 24V 14A
... Cable - Flat power Cable
... Sticker - Electric shock
Screw - Flat head countersunk M4L6 - DIN7991 _M4L6
Cable - Power switch 24V
Screw - Washer M3 - DIN125_M3
Screw - Nut M3 - DIN934_M3
Rod - Z - 12/268mm
Screw - Allen key M3L4 - DIN912_M3L4 Nickel plated
Z bush
Z screw - assy
... ma19 Z screw
... Screw - Set screw M3L4 - DIN913_M3L4 flat
... Pulley GT2 20 teeth
... ma19 Z holder
... ma19 Z coupler
... ma19 Z nut
Timing belt - closed 126mm
Z Console assy
... Block Z left
... ... ma19 Block Z
... ... Bearing - LM12UU - Linear Bearing
... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
... ... Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
... ... Z horse CBP painted
... Screw - Allen key M4L8 - DIN912_M4L8 Black
... Z Console painted
... Block Z Right
... ... ma19 Block Z
... ... Bearing - LM12UU - Linear Bearing
... ... Screw - Flat head countersunk M3L6 - DIN7991 _M3L6
... ... Energy chain - 7.7 1st end
... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
Base bed assy
... sm23_bed_base
... Bed heater Connector ATX
... Energy chain - 7.7 2nd end
... Energy chain - 7.7 9pcs
... Cable gasket, Rubber
... sm23_hot sticker holder
