CraftUnique CraftBot Plus Service Manual page 16

Part name
... Bed heater Connector MOLEX 2510
... HOT Sticker
... Build plate insulator CBP
... Bed heater CBP - 24V 180W - 205 x 246mm
... Screw - Nut M4 - DIN934_M4
Build plate spring
Build plate bush
Knurled nut - Black
Screw - Allen key M4L8 - DIN912_M4L8 Black
Z tartó - Z holder
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Screw - Flat head countersunk M3L6 - DIN7991 _M3L6
Screw - Washer M3 - DIN125_M3
Screw - Nut M3 - DIN934_M3
Cable - Z limit
... Cable gasket, Rubber
Screw - D head M2.5L1 2 - DIN7380_M2.5L1 2
Screw - Nut M2.5 - DIN934_M2.5
ma19 rod holder
Screw - Nut M3 - DIN934_M3
Rod - Y - 8/351 mm
X cross assy FFC v34
... Block X assy
... ... ma27 Block X
... ... KH0824PP
... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
... Block X2 assy
... ... ma27 Block X2
... ... KH0824PP
... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
... Rod - X - 8/331 mm
... Block Y assy
... ... ma19 Block Y
... ... KH0824PP linear ball bearing
... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
... ... Bearing - flanged - belt_F624Z
... ... Screw - Washer M4 - DIN125_M4_200HV
... ... Screw - Allen key M4L1 6 - DIN912_M4L1 6 Nickel plated
... ... Screw - Set screw M4L4 - DIN91 4_M4L4
... Extruder FFC assy
... ... Ext base FFC
... ... sm24_ext_swing
... ... Excenter handle
... ... Washer metal 3.2x6x2 extruder
... ... Washer PA 3.2x6x2 extruder
Service manual for CraftBot Plus and CraftBot 2 models
Page: 16 / 32
Copyright Craftunique ltd. All rights reserved.
Version V1.0
Order number Quantity
be.000.012
pt.000.001
bm.001.008
be.001.005
sc.003.003
bm.000.029 *
bm.000.028 *
bm.000.027 *
sc.002.016
ma.001.020
sc.002.012
sc.002.018
sc.001.001
sc.003.002
ca.002.004 *
bm.000.020
sc.002.001
sc.003.001
ma.001.009 *
sc.003.002
bm.001.006 *
pr.001.048
pr.001.007
ma.001.016
bm.000.022 *
sc.002.004
pr.001.006
ma.001.017
bm.000.022 *
sc.002.004
bm.001.005 *
pr.001.008
ma.001.002
bm.000.022 *
sc.002.004
bm.001.004 *
sc.001.002
sc.002.015
sc.002.006
pr.001.002 *
sm.001.004
sm.001.035
sm.000.001
ma.001.001
by.001.003
1
1
1
1
3
3
3
3
2
1
2
2
1
2
1
1
2
2
4
8
2
1
1
1
2
2
1
1
2
2
2
2
1
2
2
4
2
2
2
1
1
1
1
3
1
