CraftUnique CraftBot Plus Service Manual page 17

Part name
... ... NEMA 17/40 Stepper motor 20mm shaft
... ... Filament drive gear
... ... ... Screw - Set screw M3L4 - DIN913_M3L4 flat
... ... Bearing - filament - V625ZZ
... ... Extruder Spring
... ... Screw - Allen key M3L10 - DIN912_M3L10
... ... Screw - Allen key M5L10 - DIN912_M5L10
... ... Ext top FFC assy
... ... ... Ext top FFC
... ... ... ma19 Ptfe topholder
... ... Ext front FFC
... ... Hotend - assy
... ... ... ma19 Peek
... ... ... ma19 Ptfe washer
... ... ... Nozzle - MK8 0.4mm
... ... ... ma19 Cuhead w/Rubber
... ... ... ma24 Peekholder
... ... Screw - Washer M6 - DIN125_M6
... ... Screw - Nut M6 - DIN934_M6
... sm23_kabeltarto painted Cable holder
... Screw - D head M4L6 - DIN7380_M4L6
... PCB - FFC v2.0
... sm29_ffcleszorító - FFC gripper
... Screw - Allen key M3L8 - DIN912_M3L8 Nickel plated
Cable - HMI LCD
Kapcsoloanya - switch nut
Screw - D head M2.5L1 2 - DIN7380_M2.5L1 2
Spacer 4.2 X 8 X 3 - LCD
PCB - HMI v2.0 FFC
... PCB - HMI v2.0 FFC assy
... LCD - 2.8" 320 x 240 - ER-TFT028-4
Spacer M3, Nut-Nut, 15mm LCD
HMI cover - CBP
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Motor - NEMA17-26 + Damper + pulley assy
... NEMA 17/40 Stepper motor 26mm shaft
... NEMA 17 Vibration damper
... Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
... Pulley GT2 20 teeth
... Screw - Set screw M3L4 - DIN913_M3L4 flat
... Screw - Allen key M3L4 - DIN912_M3L4 Nickel plated
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated
Cable - Motor 12cm
Cable - Motor 19cm
Cable - Motor 32cm
Service manual for CraftBot Plus and CraftBot 2 models
Page: 17 / 32
Copyright Craftunique ltd. All rights reserved.
Version V1.0
Order number Quantity
be.000.007 *
bm.000.025 *
sc.002.004
bm.001.001 *
bm.000.014 *
sc.002.008
sc.002.017
pr.001.024
sm.001.006
ma.001.007 *
sm.001.005
pr.000.003 *
ma.001.006
ma.001.008
bm.000.016
ma.001.005
ma.001.015
sc.001.003
sc.003.004
sp.000.002 *
sc.002.003
el.000.001 *
sp.000.004 *
sc.002.013
ca.001.001 *
ma.000.002 *
sc.002.001
bm.000.030 *
el.000.004 *
el.000.005
be.000.005
bm.000.031 *
be.000.004
sc.002.012
pr.000.004 *
be.000.008 *
bm.000.023
sc.002.012
bm.000.024
sc.002.004
sc.002.011
sc.002.012
ca.000.003 *
ca.000.005 *
ca.000.006 *
1
1
1
1
1
4
2
1
1
1
1
1
1
1
1
1
1
1
1
1
6
1
1
2
1
1
2
4
1
1
1
4
1
4
3
1
1
2
1
1
1
6
1
1
1
