3. Exploded view - Overview
1
7
Service manual for CraftBot Plus and CraftBot 2 models
Page: 6 / 32
2
4
ITEM NO.
ORDER NUMBER
1
2
3
4
5
6
7
Copyright Craftunique ltd. All rights reserved.
Version V1.0
5
6
3
PART NAME
Frame top
Frame back
Frame assembly
Extruder assembly 1
HMI assembly
Bed assembly
Pr3Dator PCB
QTY.
1
1
1
1
1
1
