MAINTENANCE
NOTICE
To ensure adequate starting capability, always have
power applied to the generator's internal battery
charger.
BATTERY
CHARGER
JACKET WATER
HEATER
OUTPUT TERMINAL
PANEL ASSEMBLY
BATTERY CHARGER/
JACKET WATER HEATER
120 VAC INPUT
RECEPTACLE
Figure 68. Battery Charger and Jacket Water Heater (Option)
MQP56 60 HZ GENERATOR • OPERATION MANUAL — REV. #0 (06/14/17) — PAGE 45
