MULTIQUIP MQP240 Specifications

MQP240
Diesel Generator
Prime Rating — 240 kW (300 kVA)
Standby Rating — 260 kW (330 kVA)
3-Phase, 60 Hertz, 0.8 PF
STANDARD FEATURES
„ Heavy duty, turbocharged, direct injection diesel engine
provides maximum reliability.
„ Brushless alternator reduces service and maintenance
requirements and meets temperature rise standards for Class
F insulation systems.
„ Open delta alternator design provides virtually unlimited
excitation for maximum motor starting capability.
„ Automatic voltage regulator (AVR) provides precise
regulation.
„ Electronic governor system with idle switch maintains
frequency to ±0.25%.
„ Full load acceptance of standby nameplate rating in one
step (NFPA 110, para 5-13.2.6).
„ Sound attenuated, weather resistant, steel housing
provides operation at 73 dB(A) at 23 feet. Fully lockable
enclosure allows safe unattended operation.
„ Fuel/water separator removes condensation from fuel for
extended engine life.
„ E-Coat primer with polyurethane enamel finish coat.
„ Low coolant level shutdown system provides protection
from critically low coolant levels. Includes control panel
warning light.
MQP240 — DIESEL GENERATOR — REV. #1 (03/20/14)
„ Complete engine analog instrumentation includes DC
ammeter, oil pressure gauge, fuel gauge, water temp. gauge,
tachometer/hour meter, preheat indicator, manual engine
speed control, emergency shutdown monitors, and emergency
stop button.
„ Complete generator analog instrumentation includes
voltage regulator control, ammeter phase selector switch,
voltmeter phase selector switch, AC voltmeter, AC ammeter,
frequency meter, panel light, and circuit breaker.
„ Automatic safety shutdown system monitors the water
temperature, engine oil pressure, overspeed, and overcrank.
Warning lights indicate abnormal conditions.
„ Auto start/stop control allows generator to start automatically
in the event of a commercial power failure.
„ Complete power panel. Fully covered; three-phase terminals
and single phase receptacles allow fast and convenient
hookup for most applications including temporary power
boxes, tools and lighting equipment. All are NEMA standard.
„ Two stage air filter
„ Simultaneous single and three phase power
„ Emergency stop switch
„ Battery switch
„ Documentation box
„ EPA emissions certified - Tier 3 emissions compliant
„ CSA listed
