Altronix ALTV244UL Installation Manual page 4

Fig. 1
ALTV244UL
Fig. 2
ALTV244ULCB
- 4 -
24VAC or 28VAC
output 1 (Follow
same procedure
using terminals
2P & N through
1P 1N
4P & N outputs
2 through 4)
non-power
limited
Primary
In-line
Fuse
Back Panel
of Enclosure
F1 F2
24VAC or 28VAC
output 1
(Follow same
procedure using
terminals 2P & N
1P 1N 2P
through 4P & N
outputs 2 through 4)
Primary
In-line
24VAC configuration Class 2 Not Wet/Class 3 Wet
Fuse
28VAC configuration Class 1
non-power
limited
Back Panel
of Enclosure
3.5A 250V 3.5A 250V
3.5A 250V
2P 2N 3P 3N 4P 4N
N
Class 1 Outputs
XFMR
F3 F4
LED
2N 3P 3N 4P 4N
N P S
XFMR
White
Lead
SW1
LED
INPUT
P S
non-power
limited
Black
Lead
Black
Lead
115VAC
Input
60 Hz.
White
Lead
Green
Lead
(Ground)
SW1
INPUT
non-power
limited
Black
Lead
Black
Lead
115VAC
Input
60 Hz.
Green
Lead
(Ground)
ALTV244UL Series
