VADDIO WallVIEW 50i PTZ Installation And User Manual

Camera and Electronic Products for Integrators
WallVIEW™ PTZ Systems
WallVIEW 50i PTZ, WallVIEW 100 PTZ and WallVIEW 70 PTZ
Pan/Tilt/Zoom Camera Systems
Figure 1: WallVIEW Systems (left to right); WallVIEW 50i PTZ, WallVIEW 100 PTZ, WallVIEW 70 PTZ, with each camera showing
EZCamera Cabling Shoe and Thin Profile wall mount bracket.

INTRODUCTION

The Vaddio WallVIEW PTZ Camera Systems are complete wall-mounted camera
packages featuring the Vaddio EZCamera™ Cabling System that allows the installer to
use Category 5 cabling to run power, video and camera control.
PowerRite™ power supply provides the right amount of power required for proper
operation of the camera over Cat. 5 cabling.
Before installing the Vaddio WallVIEW PTZ Camera Systems, please read
INTENDED USE
the entire manual thoroughly. All Vaddio camera systems were designed
for use indoors.
tested, and could damage the camera and/or create a potentially unsafe
operating condition.
provided.
Read and understand all instructions before using. Do not operate any
IMPORTANT
electrical device if it has been dropped or damaged. In this case, a Vaddio
SAFEGUARDS
technician must examine the product before operating. To reduce the risk
of electric shock, do not immerse in water or other liquids and avoid
extremely humid conditions.
Use only the power supply provided with the Vaddio WallVIEW products.
Use of any unauthorized power supply will void any and all warranties.
Ⓒ2006 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are
subject to change without notice. Vaddio, WallVIEW, ControlVIEW, EZCamera, Quick-Connect and PowerRite are registered trademarks of
Vaddio. All other trademarks are property of their respective owners. Document Number 010-2201-000 Rev. F
Outdoor operation is not recommended, hasn't been
Use only the Vaddio PowerRite power supply
Page 1 of 8
