VADDIO WallVIEW 50i Installation And User Manual

Camera and Electronic Products for Integrators
WallVIEW
Installed PTZ Wall Camera with Recessed, Motorized In-wall Camera Lift System
INTRODUCTION
INTENDED USE
SAVE THESE
INSTRUCTIONS
Ⓒ2006 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing subject to change.
trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Form Number 341-141 Rev. C.
50i PTZ HideAway
™
The Vaddio WallVIEW 50i PTZ HideAway Camera System is a
mechanically unique and complete product that was designed to
provide system integrators with an easy to install, in-wall, recessed
and motorized camera lift system for use when cameras require
concealment for security or architectural design purposes.
WallVIEW 50i features the Canon
which is mounted in a recessed plenum rated enclosure with a
motorized front panel door. When closed, the WallVIEW HideAway
enclosure conceals the camera until the camera is activated, then
the front door drops down and reveals the camera to the meeting
room participants.
The system is equipped with Vaddio's EZCamera™ Cabling
System. This allows the integrator to use Cat. 5 cabling to run
power and video together on a single Cat.5 and camera control on
a second Cat. 5 run. The VISCA control interface is included to
allow the camera to work with any other VISCA compatible control
device. The PowerRite™ power supply regulates the right amount
of power needed for the camera over the Cat. 5 cabling.
Before operating the Vaddio WallVIEW 50i PTZ HideAway, please
read the entire manual thoroughly. The camera system was
designed, built and tested for use indoors and with the provided
power supply. The use of a power supply other than the one
provided or outdoor operation has not been tested and could
damage the camera and/or create a potentially unsafe operating
condition.
The information contained in this manual will help you install and
operate your Vaddio WallVIEW 50i PTZ HideAway.
instructions are misplaced, Vaddio keeps copies of Specifications,
Installation and User Guides and most pertinent product drawings
for the Vaddio product line on the website. These documents can
be downloaded from
CeilingVIEW, WallVIEW ControlVIEW, Quick-Connect, EZCamera and PowerRite are registered
Installation and User Guide
VC-C50i pan/tilt/zoom camera
®
www.vaddio.com free of charge.
The
If these
