Cameras and Electronic Product for Integrators
Vaddio™ WallVIEW™ CCU HD-18 HD-SDI
High-Definition HD-18 PTZ Camera featuring the EZIM HD-SDI Slot
Card and Quick-Connect CCU
Model Number 999-6908-000W (North America)
Model Number 999-6908-001W (International)
Arctic White Version
EZIM HD-SDI Card for HD-18
©2010 Vaddio - All Rights Reserved. WallVIEW CCU HD-18 SDI - Document Number 341-988 Rev. A
Installation and Guide
Model Number 999-6908-000 (North America)
Model Number 999-6908-001 (International)
Quick-Connect CCU for HD-18
Advertisement
Table of Contents
Related Manuals for VADDIO WallVIEW CCU HD-18 HD-SDI
Summary of Contents for VADDIO WallVIEW CCU HD-18 HD-SDI
- Page 1 Model Number 999-6908-001 (International) Model Number 999-6908-000W (North America) Model Number 999-6908-001W (International) Arctic White Version EZIM HD-SDI Card for HD-18 Quick-Connect CCU for HD-18 ©2010 Vaddio - All Rights Reserved. WallVIEW CCU HD-18 SDI - Document Number 341-988 Rev. A...
- Page 2 50dB, delivering clean, crisp, and clear video. The multi-element motorized zoom lens allows WallVIEW CCU HD-18 HD-SDI to capture a wide angle of view (55.2°) enough to view everyone at a conference room table, as well as capture an individual from a long distance (3.2°). The zoom range provides greater flexibility for a wide variety of applications.
- Page 3 CCU tally port on the back of the Quick-Connect CCU. IR Sensors – Dual IR sensors are built into the front of the WallVIEW CCU HD-18 HD-SDI to receive IR signals from the IR remote control supplied with the camera.
- Page 4 Do not insert or remove the EZIM HD-SDI Slot Card into an HD-18 Camera when the camera is powered ON. Detach all power connectors before installing or removing the EZIM HD-SDI Slot Card. WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 4 of 26...
- Page 5 Gain control boosts the signal level when the iris is open all the way, and there is not enough lighting available. To manually adjust the gain Auto Iris must be off. WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 5 of 26...
- Page 6 HD-SDI Console or monitor or over HD-SDI signal destination. Video RJ-45 The EZCamera Power/Video RJ-45 port is not supported with the CCU/HD-SDI system. WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 6 of 26...
- Page 7 3Gb/s single link HD-SDI. Currently, the EZIM HD-SDI coupled with the HD-18 PTZ camera can output 1080p/60, has been tested and is compatible with the single link 3Gb/s inputs of the Vaddio ProductionVIEW HD-SDI Seamless Video Switcher and Camera Controller.
-
Page 8: Installation
First Time Set-up with the WallVIEW CCU HD-18 HD-SDI: WallVIEW CCU HD-18 HD-SDI was designed to be exceptionally easy to use and operate. There is documentation at the back of the manual for pin-outs for all of the connectors on the WallVIEW CCU HD- 18 HD-SDI System. -
Page 9: Mounting And Installation Instructions
(3) to aid in alignment. Push the Slot Card in completely. ③ Figure 10: Rear View of HD-18 ② Showing Insertion of the Slot Card WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 9 of 26... -
Page 10: Firmware Versions
Place the camera onto the camera mount and using the ¼”-20 screws to secure the camera to the mount. Step 5: Connect the Vaddio 36 VDC power supply to an AC outlet. Power will travel down the Power CAT 5e cable to the camera. The camera will “Home” to a centered position ready for control information from the IR remote control or RS-232 camera controller of the integrators’... - Page 11 *Distances are approximate and based on using Belden 1694A coax cable. Results may vary according to the quality of cable used and with the ability of individual installer/integrator. **Tested with HD-SDI Receivers in the ProductionVIEW HD-SDI Console. WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 11 of 26...
- Page 12 The HD-SDI/SDI output of the Slot Card will be dependent on the output signal being fed into the slot card from the Vaddio HD-18 camera. The HD Video Resolutions are selected via the 16-position rotary switch on the HD-18 camera. A label has been placed on the bottom of the camera for reference. The HD-SDI and the YPbPr are concurrent outputs at the same resolution.
- Page 13 TALLY OUT HD-SDI Vaddio ProductionVIEW HD-SDI Camera Controller and Seamless 6X2 HD-SDI/SDI Switcher Optional Accessory – UXHD CrossPoint (999-5690-000) The Vaddio UXHD CrossPoint is a dual input (HD- SDI/SDI & analog component YPbPr or RGBHV or SD), dual output (HD-SDI/SDI &...
- Page 14 HD-SDI CAM 2 IN PREV OUT (HD-SDI PROG) HD-SDI CAM 1 IN HD-SDI PROG OUT ProductionVIEW HD-SDI HD-SDI PROGRAM HD-SDI PREVIEW RGBHV Monitor* Monitor* Projector *Simulated Video Feeds WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 14 of 26...
- Page 15 HD-SDI PROGRAM (Feed to Satellite Truck) **Simulated Video Feeds *Up to six (6) Vaddio HD-18 PTZ Cameras can be controlled by the ProductionVIEW HD-SDI Seamless Video Switcher and Joystick Camera Control Console. WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A...
-
Page 16: General Specifications
WallVIEW CCU HD-18 HD-SDI Part Numbers WallVIEW CCU HD-18 HD-SDI 999-6908-000 - North America WallVIEW CCU HD-18 HD-SDI 999-6908-000W - North America (Arctic White Version) WallVIEW CCU HD-18 HD-SDI 999-6908-001 - International WallVIEW CCU HD-18 HD-SDI 999-6908-001W - International (Arctic White Version) •... - Page 17 This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment. ICES-003 Compliance This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
- Page 18 This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment. ICES-003, Issue 4: 2004, Compliance This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
- Page 19 This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment. ICES-003 Compliance This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
-
Page 20: Warranty Information
Vaddio Customer service – Vaddio will test, repair, or replace the product or products without charge if the unit is under warranty and is found to be defective. If the product is out of warranty, Vaddio will test then repair the product or products. The cost of parts and labor charge will be estimated by a technician and confirmed by the customer prior to repair. - Page 21 Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged. In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock, do not immerse in water or other liquids and avoid extremely humid conditions.
-
Page 22: Appendix 2: Camera Dimensions
Y GND Pb GND NOTE: This output, on the back of the camera is still active, even with the EZIM HD-SDI slot card installed. Appendix 2: Camera Dimensions WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 22 of 26... -
Page 23: Appendix 3: Communication Specification
No Flow control NOTE: The Vaddio ClearVIEW HD-18 Control Protocol is similar, but not identical to the Sony™ VISCA™ command set in order to be compatible with several popular control devices. Not all VISCA commands are supported and there are many HD-18 specific commands in the following Command and Inquiry Lists. - Page 24 ICR Off Additional Information: Pan Range: 8044 – 7FBC (-32,700 to +32,700) Tilt Range: E891 – 4C2B (-5,999 to +19,499) * Actual Pan/Tilt ranges defined in Inquiry list WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 24 of 26...
- Page 25 50 00 00 0p 0q FF pq: ExpComp Pos -Iris Position CAM_ICRModeInq 81 09 04 01 FF y0 50 02 FF ICR On y0 50 03 FF ICR Off WallVIEW CCU HD-18 HD-SDI Manual 341-988 Rev. A Page 25 of 26...
- Page 26 Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464 www.vaddio.com ©2010 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to change without notice. Vaddio, ClearVIEW, ProductionVIEW, Quick-Connect, UXHD, WallVIEW, EZCamera, EZIM and PowerRite are registered trademarks of Vaddio.
