Robustel R3000 Quad User Manual

Industrial cellular vpn router with 4 ethernet ports 4 eth + 1 rs-232/1 rs-485 + 1 usb host
Hide thumbs Also See for R3000 Quad:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User Guide
User Guide
R3000 Quad
Industrial Cellular VPN Router with 4 Ethernet Ports
4 Eth + 1 RS-232/1 RS-485 + 1 USB Host
Guangzhou Robustel Technologies Co., Ltd
www.robustel.com
Guangzhou Robustel Technologies Co., Ltd.
www.robustel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R3000 Quad and is the answer not in the manual?

Questions and answers

Related Manuals for Robustel R3000 Quad

Summary of Contents for Robustel R3000 Quad

  • Page 1 User Guide User Guide R3000 Quad Industrial Cellular VPN Router with 4 Ethernet Ports 4 Eth + 1 RS-232/1 RS-485 + 1 USB Host Guangzhou Robustel Technologies Co., Ltd www.robustel.com Guangzhou Robustel Technologies Co., Ltd. www.robustel.com...
  • Page 2 The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use of this document.
  • Page 3 Robustel accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the router, or for failure of the router to transmit or receive such data.
  • Page 4 Robustel R3000 Quad User Guide Protecting Your Router To ensure error-free usage, please install and operate your router with care. Do remember the following: Do not expose the router to extreme conditions such as high humidity / rain, high temperature, direct sunlight, ...
  • Page 5 Robustel R3000 Quad User Guide Regulatory and Type Approval Information Table 1: Directives 2011/65/EC Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and...
  • Page 6 Robustel R3000 Quad User Guide Document History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Date Firmware Version Doc Version Change Description 28 May, 2017 3.0.0 v.1.0.0 Initial release RT_UG_R3000 Quad_v.3.0.0...

  • Page 7: Table Of Contents

    Robustel R3000 Quad User Guide Contents Chapter 1 Product Overview ........................... 9 Key Features ............................... 9 Package Contents ............................. 10 Specifications ............................12 Dimensions ............................... 14 Ordering Information ..........................14 Chapter 2 Hardware Installation ........................15 LED Indicators ............................15 PIN Assignment ............................
  • Page 8 Robustel R3000 Quad User Guide 3.26 Services > GPS ............................94 3.27 Services > Web Server ..........................97 3.28 Services > Advanced ..........................98 3.29 System > Debug ............................99 3.30 System > Update ............................ 100 3.31 System > APP Center ..........................101 3.32...

  • Page 9: Chapter 1 Product Overview

    Chapter 1 Product Overview 1.1 Key Features The Robustel Industrial Cellular VPN Router with 4 Ethernet Ports (R3000 Quad) is a rugged cellular router offering state-of-the-art mobile connectivity for machine to machine (M2M) applications. R3000 Quad is a powerful router developed from RobustOS, a Robustel self-developed and Linux-based operating system which is designed to be used in Robustel hardware routers.

  • Page 10: Package Contents

    1 x7-pin pluggable terminal block with lock for serial port and console port  1 x Quick Start Guide with download link of other documents or tools *If any of the above items is missing or damaged, please contact your Robustel sales representative. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017...
  • Page 11 Robustel R3000 Quad User Guide Optional accessories (sold separately):  3G/4G SMA cellular antenna (stubby/magnet optional) Stubby antenna Magnet antenna  Wall mounting kit  35 mm DIN rail mounting kit  Ethernet cable  AC/DC power adapter (12V DC, 1.5 A; EU/US/UK/AU plug optional) RT_UG_R3000 Quad_v.3.0.0...

  • Page 12: Specifications

    Robustel R3000 Quad User Guide 1.3 Specifications Cellular Interface Number of ports: 2 (MAIN + AUX)  Connector: SMA, female  SIM: 2 (3.0 V & 1.8 V)  Standards: GSM/GPRS/EDGE/WCDMA/HSDPA/HSUPA/HSPA+/DC-HSPA+/TD-SCDMA/CDMA(CDMA  1X/EVDO)/FDD LTE/TDD LTE GSM: max DL/UL = 9.6/2.7 Kbps GPRS: max DL/UL = 86 Kbps EDGE: max DL/UL = 236.8 Kbps...
  • Page 13  App Center Available apps for RobustOS: L2TP, PPTP, DMVPN, RobustVPN, VRRP, QoS, SNMP, Language, RobustLink  *Request on demand. For more APPs please visit www.robustel.com. Power Supply and Consumption Connector: 5 mm terminal block with lock  Input voltage: 9 to 60V DC ...

  • Page 14: Dimensions

    -40 to 75°C -40 to 75°C Environment 5 to 95% RH 5 to 95% RH *For more information about 4G frequency bands in different countries, please contact your Robustel sales representative. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 14 / 131 Confidential...

  • Page 15: Chapter 2 Hardware Installation

    Robustel R3000 Quad User Guide Chapter 2 Hardware Installation 2.1 LED Indicators The R3000 Quad has been designed to be placed on a desktop. Below is the front view of the R3000 Quad. Name Color Status Description Green On, fast blinking...

  • Page 16: Pin Assignment

    Robustel R3000 Quad User Guide Green On, solid High Signal strength (21-31) is available Yellow On, solid Medium Signal strength (11-20) is available On, solid Low Signal strength (1-10) is available No signal Green On, solid Connection to 4G network is established...

  • Page 17: Usb Interface

    Robustel R3000 Quad User Guide 2.3 USB Interface Function Operation Firmware USB interface is used for batch firmware upgrading, but cannot be used for sending or receiving upgrade data from slave devices which connected to it. You can insert a USB storage device into the router’s USB interface, such as a U disk or a hard disk.

  • Page 18: Reset Button

    Robustel R3000 Quad User Guide 2.4 Reset Button Function Operation Reboot Press and hold the RST button for 5 seconds under the operating status. Restore to factory Wait for 5 seconds after powering up the router, press and hold the RST button until all six...

  • Page 19: Ethernet Port

    Robustel R3000 Quad User Guide 2.5 Ethernet Port R3000 Quad Router has four Ethernet port with two LED indicators. The yellow one is link indicator and the green one is speed indicator. For details about status, see the table below.

  • Page 20: Insert Or Remove Sim Card

    Robustel R3000 Quad User Guide 2.6 Insert or Remove SIM Card Insert or remove the SIM card and SD card as shown in the following steps. Insert SIM card or SD card  Make sure router is powered off. To remove slot cover, loosen the screws associated with the cover by using a screwdriver and then find the SIM card slot.

  • Page 21: Attach External Antenna (Sma Type)

    Robustel R3000 Quad User Guide 2.7 Attach External Antenna (SMA Type) Attach an external SMA antenna to the router’s connector and twist tightly. Make sure the antenna is within the correct frequency range provided by the ISP and with 50 Ohm impedance.

  • Page 22: Connect The Router To A Computer

    Robustel R3000 Quad User Guide DIN rail mounting DIN rail size (measured in mm) Use 3 pcs of M3*6 flat head Phillips screws to fix the DIN rail to the router, and then hang the DIN rail on the mounting bracket. It is necessary to choose a standard bracket.

  • Page 23: Power Supply

    Robustel R3000 Quad User Guide 2.10 Power Supply R3000 Quad router supports reverse polarity protection, but always refers to the figure above to connect the power adapter correctly. There are two cables associated with the power adapter. Following to the color of the head, connect the cable marked red to the positive pole through a terminal block, and connect the yellow one to the negative in the same way.

  • Page 24: Chapter 3 Initial Configuration

    Robustel R3000 Quad User Guide Chapter 3 Initial Configuration The router can be configured through your web browser that including IE 8.0 or above, Chrome and Firefox, etc. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista/7/8, etc.
  • Page 25 Robustel R3000 Quad User Guide Click Properties in the window of Local Area Connection Status. Choose Internet Protocol Version 4 (TCP/IPv4) and click Properties. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 25 / 131 Confidential...
  • Page 26 Robustel R3000 Quad User Guide Two ways for configuring the IP address of PC. Obtain an IP address automatically: Use the following IP address: (Configured a static IP address manually within the same subnet of the router) Click OK to finish the configuration.

  • Page 27: Factory Default Settings

    Robustel R3000 Quad User Guide 3.2 Factory Default Settings Before configuring your router, you need to know the following default settings. Item Description Username admin Password admin ETH0 192.168.0.1/255.255.255.0, LAN mode ETH1 192.168.0.1/255.255.255.0, LAN mode ETH2 192.168.0.1/255.255.255.0, LAN mode ETH3 192.168.0.1/255.255.255.0, LAN mode...

  • Page 28: Control Panel

    Robustel R3000 Quad User Guide 3.4 Control Panel After logging in, the home page of the R3000 Quad Router’s web interface is displayed, for example. Using the original password to log in the router, the page will pop up the following tab It is strongly recommended for security purposes that you change the default username and/or password.

  • Page 29: Status

    Robustel R3000 Quad User Guide Note: The steps of how to modify configuration are as bellow: Modify in one page; Click under this page; Modify in another page; Click under this page; Complete all modification; Click 3.5 Status This page allows you to view the System Information, Internet Status and LAN Status of your router.

  • Page 30: Internet Status

    Robustel R3000 Quad User Guide Internet Status Internet Status Item Description Active Link Show the current active link. Uptime Show the current amount of time the link has been connected. IP Address Show the IP address of current link. Gateway Show the gateway address of the current link.

  • Page 31: Interface > Link Manager

    Warm Backup: The inactive link is online on standby  Load Balancing: Use two links simultaneously Note: R3000 Quad do not support warm backup and load balancing in the situation of two WWAN links. Revert Interval Specify the number of minutes that elapses before the primary link is checked if a backup link is being used in cold backup mode.
  • Page 32 Robustel R3000 Quad User Guide Link Settings allows you to configure the parameters of link connection, including WWAN1/WWAN2, WAN and WLAN. It is recommended to enable Ping detection to keep the router always online. The Ping detection increases the reliability and also costs the data traffic.
  • Page 33 Robustel R3000 Quad User Guide The window is displayed as below when disabling the “Automatic APN Selection” option. Link Settings (WWAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link.
  • Page 34 Robustel R3000 Quad User Guide Link Settings (WWAN) Item Description Default Automatic APN Click the toggle button to enable/disable the “Automatic APN Selection” Selection option. After enabling, the device will recognize the access point name automatically. Alternatively, you can disable this option and manually add the access point name.
  • Page 35 Robustel R3000 Quad User Guide Link Settings (WWAN) Item Description Default Debug Enable Click the toggle button to enable/disable this option. Enable for debugging information output. Verbose Debug Enable Click the toggle button to enable/disable this option. Enable for verbose debugging information output.
  • Page 36 Robustel R3000 Quad User Guide Link Settings (WAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link. Description Enter a description for this link. Null Connection Type Select from “DHCP”, “Static” or “PPPoE”.
  • Page 37 Robustel R3000 Quad User Guide PPPoE Settings Username Enter the username provided by your Internet Service Provider. Null Password Enter the password provided by your Internet Service Provider. Null Authentication Type Select from “Auto”, “PAP” or “CHAP” as the local ISP required.
  • Page 38 Router will obtain IP automatically from the WLAN AP if choosing “DHCP” as the connection type. The specific parameter configuration of SSID is shown as below. The window is displayed as below when choosing “Static” as the connection type. R3000 Quad Router does not support the PPPoE WLAN Connection Type. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017...
  • Page 39 Robustel R3000 Quad User Guide Link Settings (WLAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link. WLAN Description Enter a description for this link. Null Connection Type Select from “DHCP” or “Static”.
  • Page 40 Robustel R3000 Quad User Guide Secondary DNS Set the secondary DNS. Null Ping Detection Settings Enable Click the toggle button to enable/disable the ping detection mechanism, a keepalive policy of the router. Primary Server Router will ping this primary address/domain name to check that if the 8.8.8.8...

  • Page 41: Interface > Lan

    3.7 Interface > LAN This section allows you to set the related parameters for LAN port. There are four LAN ports on R3000 Quad Router, including ETH0~ETH3. The ETH0~ETH3 can freely choose from lan0~lan3, but at least one LAN port must be assigned as lan0.
  • Page 42 Robustel R3000 Quad User Guide You may click to edit the configuration of the LAN port, or click to delete the current LAN port. Now, click add a new LAN port. General Settings @ LAN Item Description Default Index Indicate the ordinal of the list.
  • Page 43 Robustel R3000 Quad User Guide The window is displayed as below when choosing “Relay” as the mode. Item Description Default DHCP Settings Enable Click the toggle button to enable/disable the DHCP function. Mode Select from “Server” or “Relay”. Server ...
  • Page 44 Robustel R3000 Quad User Guide Multiple IP You may click to add a multiple IP to the LAN port, or click to delete the multiple IP of the LAN port. Now, click to edit the multiple IP of the LAN port.
  • Page 45 Robustel R3000 Quad User Guide VLAN Settings Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to enable/disable this VLAN. Enable to make router can encapsulate and de-encapsulate the VLAN tag. Interface Choose the interface which wants to enable VLAN trunk function. Select from lan0 “lan0”, “lan1”, “lan2”...

  • Page 46: Interface > Ethernet

    3.8 Interface > Ethernet This section allows you to set the related parameters for Ethernet. There are four Ethernet ports on R3000 Quad Router, including ETH0~ETH3. The ETH0 on the router can be configured as either a WAN or a LAN port, while ETH1~ETH3 can only be configured as a LAN ports.

  • Page 47: Interface > Cellular

    3.9 Interface > Cellular This section allows you to set the related parameters of Cellular. The R3000 Quad Router has two SIM card slots, but do not support two SIM cards online simultaneously due to its single-module design. If insert single SIM card at the first time, SIM1 slot and SIM2 slots are available.
  • Page 48 Robustel R3000 Quad User Guide The window is displayed as below when choosing “Auto” as the network type. The window is displayed as below when choosing “Specify” as the band select type. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 48 / 131...
  • Page 49 Robustel R3000 Quad User Guide Cellular Item Description Default General Settings Index Indicate the ordinal of the list. SIM Card Show the currently editing SIM card. SIM1 Phone Number Enter the phone number of the SIM card. Null PIN Code Enter a 4-8 characters PIN code used for unlocking the SIM.
  • Page 50 Robustel R3000 Quad User Guide Click the row of status, the details status information will be displayed under the row. Status Item Description Index Indicate the ordinal of the list. Modem Status Show the status of the radio module. Modem Model Show the model of the radio module.

  • Page 51: Interface > Wifi

    Robustel R3000 Quad User Guide Status Item Description IMEI Show the IMEI (International Mobile Equipment Identity) number of the radio module. Firmware Version Show the current firmware version of the radio module. This page allows you to check the AT Debug.
  • Page 52 Robustel R3000 Quad User Guide Click the Access Point column to configure the parameters of WiFi AP. By default, the security mode is set as “Disabled”. The window is displayed as below when setting “WPA” as the security mode. RT_UG_R3000 Quad_v.3.0.0...
  • Page 53 Robustel R3000 Quad User Guide The window is displayed as below when setting “WEP” as the security mode. General Settings @ Access Point Item Description Default Enable Click the toggle button to enable/disable the WiFi access point option. Band Select from “2.4G” or “5G”.
  • Page 54 Robustel R3000 Quad User Guide General Settings @ Access Point Item Description Default SSID Enter the Service Set Identifier, the name of your wireless router network. The SSID of a client and the SSID of the AP must be identical for the client and AP to be able to communicate with each other.
  • Page 55 Robustel R3000 Quad User Guide General Settings @ Access Point Item Description Default WEP Key Enter the WEP key. The key length should be 10 or 26 Null hexadecimal digits depending on which WEP key is used, 64 digits or 128 digits.

  • Page 56: Wifi Client

    Robustel R3000 Quad User Guide Item Description Default “Access Control List” at one time. Access Control List Index Indicate the ordinal of the list. Description Enter a description for this access control list. Null MAC Address Add a MAC address here.
  • Page 57 Robustel R3000 Quad User Guide Click Interface > Link Manager > Link Settings, and click the edit button of WLAN, then configure its related parameters. Click Interface > WLAN to configure the parameters of WiFi Client after setting the mode as Client. Please remember to click Save &...

  • Page 58: Interface > Usb

    Robustel R3000 Quad User Guide This window allows you to scan for all available SSIDs in your area and connect to one of those shown on the “Scan Results” list. 3.11 Interface > USB This section allows you to set the USB parameters. The USB interface of the router can be used for firmware upgrade and configuration upgrade.

  • Page 59: Interface > Serial Port

    3.12 Interface > Serial Port This section allows you to set the serial port parameters. R3000 Quad Router supports one RS-232 or one RS-485 across a 7-pin terminal block with lock. Serial port provides a way to transfer serial data to IP data, or vice versa, and transmit these data via wired or wireless network to achieve data transparent transmission.
  • Page 60 Robustel R3000 Quad User Guide “57600” , “115200” or “230400”. Data Bits Select from “7” or “8”. Stop Bits Select from “1” or “2”. Parity Select from “None”, “Odd” or “Even”. None Flow control Select from “None”, “Software” or “Hardware”.
  • Page 61 Robustel R3000 Quad User Guide The window is displayed as below when choosing “Transparent” as the application mode and “Robustlink” as the protocol.  The window is displayed as below when choosing “Modbus RTU Gateway” as the application mode and “TCP Client”...
  • Page 62 Click the “Status” column to view the type which the current serial port corresponds. The default setting of serial port is RS-485, changed by software. Software selectable refers to change the serial port to RS-232 or RS-485 through an importing APP. Note: To change your serial type, please contact your Robustel sales representative. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017...

  • Page 63: Network > Route

    Robustel R3000 Quad User Guide 3.13 Network > Route This section allows you to set the static route. Static route is a form of routing that occurs when a router uses a manually-configured routing entry, rather than information from a dynamic routing traffic. Route Information Protocol (RIP) is widely used in small network with stable use rate.

  • Page 64: Network > Firewall

    Robustel R3000 Quad User Guide Status This window allows you to view the status of route. 3.14 Network > Firewall This section allows you to set the firewall and its related parameters, including Filtering, Port Mapping and DMZ. Filtering The filtering rules can be used to either accept or block certain users or ports from accessing your router.
  • Page 65 Robustel R3000 Quad User Guide Filtering Item Description Default Default Filtering Policy Select from “Accept” or “Drop”. Cannot be changed when filtering Accept rules table is not empty.  Accept: Router will accept all the connecting requests except the hosts which fit the drop filter list ...
  • Page 66 Robustel R3000 Quad User Guide Click to add a filtering rule. The maximum count is 20. The window is displayed as below when defaulting “All” or choosing “ICMP” as the protocol. Here take “All” as an example. The window is displayed as below when choosing “TCP”, “UDP” or “TCP-UDP” as the protocol. Here take “TCP” as an example.

  • Page 67: Port Mapping

    Robustel R3000 Quad User Guide Filtering Rules Item Description Default Protocol Select from “All”, “TCP”, “UDP”, “ICMP” or “TCP-UDP”. Note: It is recommended that you choose “All” if you don’t know which protocol of your application to use. Action Select from “Accept” or “Drop”.

  • Page 68: Network > Ip Passthrough

    Robustel R3000 Quad User Guide DMZ host is a host on the internal network that has all ports exposed, except those ports otherwise forwarded. DMZ Settings Item Description Default Enable DMZ Click the toggle button to enable/disable DMZ. Host IP Address Enter the IP address of the DMZ host on your internal network.
  • Page 69 Robustel R3000 Quad User Guide General Settings @ General Item Description Default Enable NAT Traversal Click the toggle button to enable/disable the NAT Traversal function. This option must be enabled when router under NAT environment. Keepalive Set the keepalive time, measured in seconds. The router will send packets to NAT server every keepalive time to avoid record remove from the NAT list.
  • Page 70 Robustel R3000 Quad User Guide destination Protocol Select the security protocols from “ESP” and “AH”.  ESP: Use the ESP protocol  AH: Use the AH protocol Local Subnet Enter the local subnet’s address with mask protected by IPsec, e.g. 192.168.1.0/24...
  • Page 71 Robustel R3000 Quad User Guide The window is displayed as below when choosing “xAuth PSK” as the authentication type. The window is displayed as below when choosing “xAuth CA” as the authentication type. IKE Settings Item Description Default Negotiation Mode Select from “Main”...
  • Page 72 Robustel R3000 Quad User Guide IKE Settings Item Description Default IKE DH Group Select from “DHgroup2”, “DHgroup5”, “DHgroup14”, “DHgroup15”, DHgroup2 “DHgroup16”, “DHgroup17” or “DHgroup18” to be used in key negotiation phase 1. Authentication Type Select from “PSK”, “CA”, “xAuth PSK” and “xAuth CA” to be used in IKE negotiation.
  • Page 73 Robustel R3000 Quad User Guide If click VPN > IPsec > Tunnel > General Settings, and choose ESP as protocol. The specific parameter configuration is shown as below. If choose AH as protocol, the window of SA Settings is displayed as below.
  • Page 74 Robustel R3000 Quad User Guide SA Settings Item Description Default Encrypt Algorithm Select from “3DES”, “AES128” or “AES256” when you select “ESP” in 3DES “Protocol”. Higher security means more complex implementation and lower speed. DES is enough to meet general requirements. Use 3DES when high confidentiality and security are required.
  • Page 75 Robustel R3000 Quad User Guide Status This section allows you to view the status of the IPsec tunnel. x509 User can upload the X509 certificates for the IPsec tunnel in this section. x509 Item Description Default X509 Settings Tunnel Name Choose a valid tunnel.

  • Page 76: Vpn > Openvpn

    Robustel R3000 Quad User Guide 3.17 VPN > OpenVPN This section allows you to set the OpenVPN and the related parameters. OpenVPN is an open-source software application that implements virtual private network (VPN) techniques for creating secure point-to-point or site-to-site connections in routed or bridged configurations and remote access facilities Router supports point-to-point and point-to-points connections.
  • Page 77 Robustel R3000 Quad User Guide The window is displayed as below when choosing “P2P” as the mode. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 77 / 131 Confidential...
  • Page 78 Robustel R3000 Quad User Guide The window is displayed as below when choosing “Preshared” as the authentication type. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 78 / 131 Confidential...
  • Page 79 Robustel R3000 Quad User Guide The window is displayed as below when choosing “Password” as the authentication type. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 79 / 131 Confidential...
  • Page 80 Robustel R3000 Quad User Guide The window is displayed as below when choosing “X509CA” as the authentication type. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 80 / 131 Confidential...
  • Page 81 Robustel R3000 Quad User Guide The window is displayed as below when choosing “X509CA Password” as the authentication type. General Settings @ OpenVPN Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to enable/disable this OpenVPN tunnel.
  • Page 82 Robustel R3000 Quad User Guide General Settings @ OpenVPN Item Description Default Authentication Type Select from “None”, “Preshared”, “Password”, “X509CA” and “X509CA None Password”. “None” and “Preshared” authentication type are only working with p2p mode. Username Enter the username used for “Password” or “X509CA Password”...
  • Page 83 Robustel R3000 Quad User Guide Advanced Settings @ OpenVPN Item Description Default Enable HMAC Firewall Click the toggle button to enable/disable this option. Add an additional layer of HMAC authentication on top of the TLS control channel to protect against DoS attacks.

  • Page 84: Vpn > Gre

    Robustel R3000 Quad User Guide @crl.pem @client.p12 Certificate Files Index Indicate the ordinal of the list. Filename Show the imported certificate’s name. Null File Size Show the size of the certificate file. Null Last Modification Show the timestamp of that the last time to modify the certificate file.

  • Page 85: Services > Syslog

    Robustel R3000 Quad User Guide Local Virtual IP Address Set the local virtual IP address of the GRE tunnel. Null Local Virtual Netmask Set the local virtual Netmask of the GRE tunnel. Null Remote Virtual IP Address Set the remote virtual IP Address of the GRE tunnel.

  • Page 86: Services > Event

    Robustel R3000 Quad User Guide Syslog Settings Item Description Default Enable Click the toggle button to enable/disable the Syslog settings option. Syslog Level Select from “Debug”, “Info”, “Notice”, “Warning” or “Error”, which from low to Debug high. The lower level will output more syslog in details.
  • Page 87 Robustel R3000 Quad User Guide Click button to add an Event parameters. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 87 / 131 Confidential...
  • Page 88 Robustel R3000 Quad User Guide General Settings @ Notification Item Description Default Index Indicate the ordinal of the list. Description Enter a description for this group. Null Sent SMS Click the toggle button to enable/disable this option. When enabled, the router will send notification to the specified phone numbers via SMS if event occurs.

  • Page 89: Services > Ntp

    Robustel R3000 Quad User Guide Event Details Item Description Default Save Position Select the events’ save position from “RAM” or “NVM”.  RAM: Random-access memory  NVM: Non-Volatile Memory Filter Message Enter the filtering message based on the keywords set by users. Click the “Refresh”...

  • Page 90: Services > Sms

    Robustel R3000 Quad User Guide NTP Server Settings Enable Click the toggle button to enable/disable the NTP server option. This window allows you to view the current time of router and also synchronize the router time. Click button to synchronize the router time with the PC’s.

  • Page 91: Services > Email

    Robustel R3000 Quad User Guide User can test the current SMS service whether it is available in this section. SMS Testing Item Description Default Phone Number Enter the specified phone number which can receive the SMS from router. Null Message Enter the message that router will send it to the specified phone number.

  • Page 92: Services > Ddns

    Robustel R3000 Quad User Guide Email Settings Item Description Default Outgoing server Enter the SMTP server IP Address or domain name. Null Server port Enter the SMTP server port. Timeout Set the max time for sending email to SMTP server. When the server doesn’t receive the email over this time, it will try to resend.

  • Page 93: Services > Ssh

    Robustel R3000 Quad User Guide Corresponding service provider. Hostname Enter the hostname provided by the DDNS server. Null Username Enter the username provided by the DDNS server. Null Password Enter the password provided by the DDNS server. Null Enter the URL customized by user.

  • Page 94: Services > Gps

    Robustel R3000 Quad User Guide Import Authorized Keys Item Description Authorized Keys Click on “Choose File” to locate an authorized key from your computer, and then click “Import” to import this key into your router. Note: This option is valid when enabling the password logins option.
  • Page 95 Robustel R3000 Quad User Guide The window is displayed as below when choosing “TCP Server” as the protocol. The window is displayed as below when choosing “UDP” as the protocol. Server Settings Item Description Default Index Indicate the ordinal of the list.
  • Page 96 Robustel R3000 Quad User Guide Server Settings Item Description Default Send GGA Sentence Send GGA information in NMEA format. Send VTG Sentence Send VTG information in NMEA format. Send RMC Sentence Send RMC information in NMEA format. Send GSV Sentence Send GSV information in NMEA format.

  • Page 97: Services > Web Server

    Robustel R3000 Quad User Guide Click “Map” column to view the current location of the router. 3.27 Services > Web Server This section allows you to modify the parameters of Web Server. General Settings @ Web Server Item Description Default HTTP Port Enter the HTTP port number you want to change in router’s Web Server.

  • Page 98: Services > Advanced

    Robustel R3000 Quad User Guide receive from a Web client. If you configure the router with other HTTPS Port number except 443, only adding that port number then you can login router’s Web Server. Note: HTTPS is more secure than HTTP. In many cases, clients may be exchanging confidential information with a server, which needs to be secured in order to prevent unauthorized access.

  • Page 99: System > Debug

    Robustel R3000 Quad User Guide “IPSec” or “WiFi”.  None: Meaningless indication, and the LED is off  OpenVPN: USR indicator showing the OpenVPN status  IPSec: USR indicator showing the IPsec status  WiFi: USR indicator showing the WiFi status Note: For more details about USR indicator, see “2.1 LED Indicators”.

  • Page 100: System > Update

    Robustel R3000 Quad User Guide Syslog Item Description Default Syslog Details Log Level Select from “Debug”, “Info”, “Notice”, “Warn”, “Error” which from low to high. Debug The lower level will output more syslog in detail. Filtering Enter the filtering message based on the keywords. Use “&” to separate more Null than one filter message, such as “keyword1&keyword2”.

  • Page 101: System > App Center

    File Click on “Choose File” to locate the App file from your computer, and then click to import this file into your router. Note: File format should be xxx.rpk, e.g. R3000 Quad-robustlink-1.0.0.rpk. Installed Apps Index Indicate the ordinal of the list.

  • Page 102: System > Tools

    Robustel R3000 Quad User Guide 3.32 System > Tools This section provides users three tools: Ping, Traceroute and Sniffer. Ping Item Description Default IP address Enter the ping’s destination IP address or destination domain. Null Number of Requests Specify the number of ping requests.
  • Page 103 Robustel R3000 Quad User Guide Traceroute Item Description Default Trace Address Enter the trace’s destination IP address or destination domain. Null Trace Hops Specify the max trace hops. Router will stop tracing if the trace hops has met max value no matter the destination has been reached or not.

  • Page 104: System > Profile

    Robustel R3000 Quad User Guide Sniffer Item Description Default Interface Choose the interface according to your Ethernet configuration. Host Filter the packet that contain the specify IP address. Null Packets Request Set the packet number that the router can sniffer at a time.
  • Page 105 Robustel R3000 Quad User Guide Ignore Invalid Settings Click the toggle button as “OFF” to ignore invalid settings. XML Configuration File Click on to locate the XML configuration file from your computer, and then click to import this file into your router.

  • Page 106: System > User Management

    Robustel R3000 Quad User Guide 3.34 System > User Management This section allows you to change your username and password, and create or manage user accounts. One router has only one super user who has the highest authority to modify, add and manage other common users.
  • Page 107 Robustel R3000 Quad User Guide Common User Settings Item Description Default Index Indicate the ordinal of the list. Role Select from “Visitor” and “Editor”. Visitor  Visitor: Users only can view the configuration of router under this level  Editor: Users can view and set the configuration of router under this level Username Set the Username;...

  • Page 108: Chapter 4 Configuration Examples

    Robustel R3000 Quad User Guide Chapter 4 Configuration Examples 4.1 Cellular 4.1.1 Cellular Dial-Up This section shows you how to configure the primary and backup SIM card for Cellular Dial-up. Connect the router correctly and insert two SIM, then open the configuration page. Under the homepage menu, click Interface > Link Manager >...
  • Page 109 Robustel R3000 Quad User Guide When finished, click Submit > Save & Apply for the configuration to take effect. The window is displayed below by clicking Interface > Cellular > Advanced Cellular Settings. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 109 / 131...

  • Page 110: Sms Remote Control

    4.1.2 SMS Remote Control R3000 Quad supports remote control via SMS. You can use following commands to get the status of the router, and set all the parameters of the router. There are three authentication types for SMS control. You can select from “Password”, “Phonenum”...
  • Page 111 Robustel R3000 Quad User Guide XML command: <lan > <network max_entry_num="2" > <id > 1</id > <interface > lan0</interface > <ip > 172.16.7.29</ip > <netmask > 255.255.0.0</netmask > <mtu > 1500</mtu > SMS cmd: set lan network 1 interface lan0 set lan network 1 ip 172.16.7.29...

  • Page 112: Network

    Robustel R3000 Quad User Guide admin:admin;reboot In this command, username is “admin”, password is “admin”, and the command is to reboot the Router. SMS received: admin:admin;set firewall remote_ssh_access false;set firewall remote_telnet_access false In this command, username is “admin”, password is “admin”, and the command is to disable the remote_ssh and remote_telnet access.
  • Page 113 Robustel R3000 Quad User Guide IPsec VPN_Server: Cisco 2811: RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 113 / 131 Confidential...
  • Page 114 Robustel R3000 Quad User Guide IPsec VPN_Client: The window is displayed as below by clicking VPN > IPsec > Tunnel. Click button and set the parameters of IPsec Client as below. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 114 / 131 Confidential...
  • Page 115 Robustel R3000 Quad User Guide When finished, click Submit > Save & Apply for the configuration to take effect. The comparison between server and client is as below. RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 115 / 131 Confidential...

  • Page 116: Openvpn

    Robustel R3000 Quad User Guide 4.2.2 OpenVPN OpenVPN supports two modes, including Client and P2P. Here takes Client as an example. OpenVPN_Server: Generate relevant OpenVPN certificate on the server side firstly, and refer to the following commands to configuration the Server: local 202.96.1.100...
  • Page 117 Robustel R3000 Quad User Guide Note: For more configuration details, please contact your technical support engineer. OpenVPN_Client: Click VPN > OpenVPN > OpenVPN as below. Click to configure the Client01 as below. When finished, click Submit > Save & Apply for the configuration to take effect.

  • Page 118: Gre Vpn

    Robustel R3000 Quad User Guide 4.2.3 GRE VPN The configuration of two points is as follows. The window is displayed as below by clicking VPN > GRE > GRE. GRE-1 ： Click button and set the parameters of GRE-1 as below.
  • Page 119 Robustel R3000 Quad User Guide GRE-2: Click button and set the parameters of GRE-1 as below. When finished, click Submit > Save & Apply for the configuration to take effect. The comparison between GRE-1 and GRE-2 is as below. RT_UG_R3000 Quad_v.3.0.0...

  • Page 120: Chapter 5 Introductions For Cli

    Robustel R3000 Quad User Guide Chapter 5 Introductions for CLI 5.1 What Is CLI Command-line interface (CLI) is a software interface providing another way to set the parameters of equipment from the SSH or through a telnet network connection. Route login:...

  • Page 121: How To Configure The Cli

    Example 2: Update firmware via tftp # tftpupdate (space+?) firmware New firmware # tftpupdate firmware (space+?) String Firmware name # tftpupdate firmware R3000 Quad-firmware-sysupgrade-unknown.bin host 192.168.100.99 //enter a new firmware name Downloading RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 121 / 131...
  • Page 122 Robustel R3000 Quad User Guide R3000 Quad-firmware-s 100% |*******************************| 5018k 0:00:00 ETA Flashing Checking 100% Decrypting 100% Flashing 100% Verifying 100% Verfify Success upgrade success //update success # config save_and_apply // save and apply current configuration, make you configuration effect...
  • Page 123 Robustel R3000 Quad User Guide Enum Primary Link (wwan1/wwan2/wan) # set link_manager primary_link wwan1 //select “wwan1” as primary_link //setting succeed # set link_manager link 1 type Type desc Description connection_type Connection Type wwan WWAN Settings static_addr Static Address Settings pppoe...
  • Page 124 Robustel R3000 Quad User Guide netmask = 255.255.255.0 mtu = 1500 dhcp { enable = true mode = server relay_server = "" pool_start = 192.168.0.2 pool_end = 192.168.0.100 netmask = 255.255.255.0 gateway = "" primary_dns = "" secondary_dns = ""...
  • Page 125 Robustel R3000 Quad User Guide Example 5: CLI for setting Cellular # show cellular all sim { id = 1 card = sim1 phone_number = "" extra_at_cmd = "" network_type = auto band_select_type = all band_gsm_850 = false band_gsm_900 = false...
  • Page 126 Robustel R3000 Quad User Guide band_wcdma_1900 = false band_wcdma_2100 = false band_lte_800 = false band_lte_850 = false band_lte_900 = false band_lte_1800 = false band_lte_1900 = false band_lte_2100 = false band_lte_2600 = false band_lte_1700 = false band_lte_700 = false band_tdd_lte_2600 = false...

  • Page 127: Commands Reference

    Robustel R3000 Quad User Guide band_lte_1900 LTE 1900 (band 2) band_lte_2100 LTE 2100 (band 1) band_lte_2600 LTE 2600 (band 7) band_lte_1700 LTE 1700 (band 4) band_lte_700 LTE 700 (band 17) band_tdd_lte_2600 TDD LTE 2600 (band 38) band_tdd_lte_1900 TDD LTE 1900 (band 39)

  • Page 128: Glossary

    Robustel R3000 Quad User Guide Glossary Abbr. Description Alternating Current Access Point Name ASCII American Standard Code for Information Interchange Conformité Européene (European Conformity) CHAP Challenge Handshake Authentication Protocol Command Line Interface for batch scripting Circuit Switched Data Clear to Send...
  • Page 129 Robustel R3000 Quad User Guide Abbr. Description local area network Light Emitting Diode Machine to Machine Maximum Minimum Mobile Originated Mobile Station Mobile Terminated OpenVPN Open Virtual Private Network Password Authentication Protocol Personal Computer Personal Communications Network, also referred to as DCS 1800...
  • Page 130 Robustel R3000 Quad User Guide Abbr. Description VSWR Voltage Stationary Wave Ratio Wide Area Network RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 130 / 131 Confidential...
  • Page 131 Robustel R3000 Quad User Guide Guangzhou Robustel Technologies Co., Ltd. Add: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Guangzhou, China 510660 Web: www.robustel.com Email: info@robustel.com Tel: 086-20-29019902 RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 131 / 131 Confidential...
