RUGGEDCOM RMC40
Installation Guide
Section 3.2

Fiber Optic Ethernet Ports

Fiber optic Ethernet ports are available with either MTRJ (Mechanical Transfer Registered Jack), LC (Lucent
Connector), SC (Standard or Subscriber Connector) or ST (Straight Tip) connectors. Make sure the Transmit (Tx)
and Receive (Rx) connections of each port are properly connected and matched to establish a proper link.
Available Ports
1
Figure 8: MTRJ Port
1. Tx Connector 2. Rx Connector
1
Figure 10: SC Port
1. Tx Connector 2. Rx Connector
Specifications
For specifications on the available fiber optic Ethernet ports, refer to
Specifications".
Fiber Optic Ethernet Ports
2
Figure 9: LC Port
1. Tx Connector 2. Rx Connector
2
Figure 11: ST Port
1. Tx Connector 2. Rx Connector
1
1
Section 4.3, "Fiber Optic Ethernet Port
Chapter 3
Communication Ports
2
2
