6.1.6

ERROR Commands Output

The XE and XEH commands return a representation of any existing error conditions as described in the following
table. If more than one error condition exists, the number returned is the sum of the values representing the error
conditions. The XE command returns the value as a decimal representation and the XEH command returns the
value as a hexadecimal representation.
XE Error Code
0
1
2
4
8
16
32
64
32768
65536
131072
262144
524288
1048576
2097152
4194304
8388608
16777216
6.1.7

Batching Control Commands

Command
BATSTART
BATSTOP
BATPAUSE
BATRESET
68 880 Installation Manual
(decimal)
no errors
VIRGERR
PARMCHKERR
LOADCHKERR
PRINTCHKERR
ENVRAMERR
ENVCRCERR
BATTERYERR
GRAVERR
ADPHYSICALERR
TAREERR
EACCOVER
STRINGERR
RESERVED_PF
RTCERR
MISSINGHWERR
CFGCONFLICTERR
UNRECOVERABLEERR
Table 6-21. XE and XEH EDP Commands Output
Batch start. If the BATRUN digital input is active (low) or not assigned, the BATSTART command can
be used to start the batch program.
If the BATRUN is inactive (high), the BATSART command will reset the batch program to the first
batch step.
Batch stop. Stops the batch program at the current batch step and turns off all associated digital
outputs.
Batch pause. Stops the batch program at the current step. All digital outputs set on by the current
step (except for those set by concur setpoints) are set off. The BATSTR digital input or BATSTART
serial command can be used to restart the batch program at the current step.
Batch reset. Stops the program and resets the batch program to the first batch step. Run the
BATRESET command after making changes to the batch configuration.
Table 6-22. Batching Control Commands
