1.4.7

Print Ticket

1. Wait for the (
PRINT
2. Press to send data to a communications port.
1.4.8

Front Panel Setup

MENU
1. Press to enter user setup mode. Use user setup to:
• View audit trail information
• Enter setup mode if audit trail is enabled
• View or set time and date
• View or clear the accumulator
• Change setpoint values and enable/diable setpoints
• View the current tare value
1.4.9

Setpoints

Setpoints must be enabled in the setup mode to be accessible in the user setup mode.
To enter the setup mode:
1. Remove the large fillister head screw from the back of the enclosure.
2. Insert a nonconductive tool into the access hole and press the setup switch. Indicator display changes to
show SCALE .
until SETPTS is displayed.
3. Press or
4. Press , SP CFG is displayed.
5. Press , press
6. Press to enter setpoint settings.
7. Select the type by pressing
options see Section 3.2.11.
8. When all settings have been made, press
Note
Setpoints are now accessible from the front panel menu.
Display or Edit Setpoint Value
. AUDIT is displayed.
MENU
1. Press
until SETPTS is displayed.
2. Press or
3. Press and the first available setpoint number is displayed.
4. Press or to toggle through each setpoint that is operator accessible.
5. Press , VALUE is displayed.
6. Press again to display or edit the value. To edit the value:
• Press or to increment or decrement the value of the flashing digit.
• Press or to select the digit to edit.
TARE
• Press
• Press or to adjust the decimal point placement.
TARE
7. Press to accept the displayed value.
8. Repeat the above steps to set PREACT, if enabled
9. When all settings have been made, press
6 880 Installation Manual
) LED to light.
or to desired setpoint number.
or to desired setting, then press
to move to the decimal point entry.
MENU
to return to weighing mode.
MENU
to return to weighing mode.
to set the value. For complete list of
