7.
Attach the replacement rear sensor (Fig. 22A) to the mounting plate (Fig. 22B) using two
head self-tapping screws (Fig. 22C). Orientation is imperative for the correct operation of the leveling
system.
8.
Attach the mounting plate (Fig. 23C) and replacement sensor (Fig. 23B) assembly to the crossmember
(Fig. 23A) using two
to side on the frame and that the sensor is oriented properly (Fig. 23).
Rev: 05.23.2017
3/8
" hex head self tapping screws (Fig. 23D). Ensure that the plate is centered side
Fig. 22
Fig. 23
Page 14
3/8
" hex
A
B
C
A
B
C
D
