4. Push Network Server.
5. To connect to a folder on an FTP server, do the steps that follow.
a. Select FTP.
b. Push FTP Server.
6. To connect to a folder on a Netdrive, do the steps that follow.
a. Select Netdrive.
b. Push Netdrive Setup.
7. Select an option.
Option Description
IP-Address Selects the IP address of the FTP server or Netdrive. Push IP-Address and enter the IP
address of the FTP server or Netdrive.
Server Name Selects the server name of the FTP server or Netdrive. Push Server Name and enter the
server name of the FTP server or Netdrive.
8. Push Data Folder, then enter the name of the target folder that is on the FTP server or Netdrive.
9. Push User, then enter a user name that has read/write permissions for the target folder.
10. Push Password, then enter the password for the user name.
11. Push OK three times.

Connect to a network printer

Pre-requisites: Connect the instrument to a LAN. Refer to
Connect a network printer to the instrument to send data to a remote (network) printer. Only network
printers that are SNMP enabled and in the same sub network are found by the instrument.
1. Push two times, then push Setup.
2. Push Network & Peripherals.
3. Select Printer, then push Setup.
4. Push Network Printer, then select On.
5. Push Printer IP, then select Automatic.
6. When the printer list shows, select a printer and then push OK.
7. Push Resolution, then select the printer resolution (100 or 150 dpi).
8. Push Paper, then select the paper size. Options: Letter, Legal, Executive or A4.
9. Push OK two times.

Connect to an sc controller

Pre-requisites: Connect the instrument to a LAN. Refer to
Connect the instrument to one or more sc controllers that have a LAN connection
that follow.
• Show the current readings from an sc controller(s).
• Show previous readings from an sc controller(s) for the day, week or month in graph format.
• Show the current reading for one parameter from an sc controller in the sidebar menu.
Note: This task is not necessary to compare process and laboratory measurements with Link2SC.
1. Push two times, then push Setup.
2. Push Network & Peripherals.
3. Select Controller, then push Setup.
4
Refer to the sc controller documentation to set up a LAN connection.
Set up a LAN connection
Set up a LAN connection
on page 16.
on page 16.
4
to do the tasks
English 17
