Removing the crankshaft

•
Remove the clutch.
•
Remove the tone wheel and the oil
pump gear.
•
Working from the generator side, un-
screw and remove the nut.
•
Remove both gears.
•
Remove the connecting rods.
•
Undo and remove the eight fixing
screws and collect the washers.
•
Hold the crankshaft during flange re-
moval.
•
With the suitable special tool, hold the
flange under slight tension by tighten-
ing the central screw of the tool itself,
simultaneously heating the outer part
of the flange for about twenty minutes.
•
Complete the removal of the crank-
shaft flange by further tightening the
central screw of the special tool. If
there are still difficulties removing it,
heat the area.
•
Remove the sealing ring from the
flange, if necessary.
Specific tooling
12.91.36.00 Tool to remove the flywheel-side
flange
Engine
ENG - 171
