MOTO GUZZI GRISO 8V - 1200 Service Station Manual page 85

GRISO 8V - 1200
Installing the engine to the vehicle
•
Place the vehicle chassis over the en-
gine with the gear.
•
From the back, secure the chassis with
belts attached to a hoist.
•
From the front, secure the vehicle with
belts attached to the handlebar and
fixed to the work bench.
•
Lift the engine placing it in position.
•
Connect the oil pressure sensor con-
nector.
•
Working from the left side, fit the en-
gine upper bolt with the washer.
•
From the opposite side, fit the washer
and screw the nut.
•
Working on both sides, insert the
washer and screw the screw without
tighten it.
•
Place the plate and the cable guide and
fix them using the two screws.
Engine from vehicle
ENG VE - 85
