- Page 1 CETH-4HDMI Ethernet/USB to 4 Port HDMI Converter Operation Manual Draft Manual CETH-4HDMI...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirement ..............1 5. Features ..................2 6. Specifications ................2 7. Hardware Description ..............3 7.1 Front Panel ................ 3 7.2 Real Panel ................. 3 8. Software Installation .............. -
Page 5: Introduction
1. Introduction The CETH-4 HDMI Ethernet/USB to 4 Port HDMI Converter is a networked HDMI system that allows you to display PC/ Laptop content on up to four HDMI displays and features three operation modes: A LAN Mode, a USB Mode and an Extender Mode. -
Page 6: Features
5. Features • Displaying content on up to 4 HDMI displays from through a networked system or directly from PC/Laptop with USB cable • HD resolution up to 1920 x 1080 for each HDMI output • Individual EDID selection with output display control •... -
Page 7: Hardware Description
7. Operation Controls and Functions 7.1 Front Panel Power Switch: Turn the system ON/OFF. ① . HDMI output enable and LED indicators: Press the HDMI output enable button to enable/disable the corresponding HDMI output ports. When enable the corresponding HDMI output port the BLUE LED will illuminate, when disable the HDMI output the BLUE LED will not illuminate. - Page 8 7.2 Rear Panel . EDID Control switch: Each EDID control switch is determined if you are ① going to use the EDID from the display or use an onboard EDID. When select to TV, the EDID will attach to output TV. When selected to INT, the EDID will become onboard EDID and the factory default setting is in TV mode.
-
Page 9: Software Installation
8. Software Installation The following sections list the procedures to follow when installing the USB to HDMI and USB device drivers. Insert the provided CD into your CD-ROM drive, then begin the USB Install Disc and follow the below steps to install the driver. 8.1 Install DisplayLink Software Select the preferred language and click automatically check for updates, and then click “... - Page 10 Screen Resolution: Select the screen resolution (available only in extended mode). NOTE: When the display has a built in EDID the screen will show the displays resolution, if no EDID is present the screen has the following resolution (see below image) Color Quality: Select the screen color quality (available only in ...
- Page 11 Extend to: Reposition the extended screen to the top, bottom, left or right of the primary display. Extend: Set the DisplayLink Manager to Extended mode. Set as Main Monitor: Set the monitor to be the main monitor. ...
- Page 12 Notebook Monitor off: Set the PC/notebook's monitor off. Mirror: Set the DisplayLink Manager to Mirror mode. You can see the same desktop image on the additional monitor. Off: Disable the DisplayLink Manager on the system. ...
-
Page 13: Using More Displaylink Manager
Advanced: Opening the Display Properties will allow you to adjust the resolution, color quality, position and refresh rate. 9.2 Using More DisplayLink manager You don ’ t have to install a new driver as long as you have completed the above installation process in advance. It will automatically define the ID of the new Display Link Manager and will list everything in the Display properties or the display manager menu. -
Page 14: Connection And Installation
10. Connection and Installation Extender Mode RJ45 LAN Mode RJ45 RJ45(100M) -
Page 15: Acronyms
Acronyms Acronym Complete Term HDMI High-Definition Multimedia Interface... - Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw MPM-CETH4HDMI...
