Gemini 932IT Installation And User Manual
Hide thumbs Also See for 932IT:

Advertisement

932IT
INSTALLATION AND

USER GUIDE

UK
Rev.00 - 03/17
Made in Italy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 932IT and is the answer not in the manual?

Questions and answers

Summary of Contents for Gemini 932IT

  • Page 1: User Guide

    932IT INSTALLATION AND USER GUIDE Rev.00 - 03/17 Made in Italy...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS - INTRODUCTORY NOTE................... PAG. 03 USER GUIDE PAG. 03 - OPERATING INSTRUCTIONS................... PAG. 03 2.1 - Complete system arming..................PAG. 03 2.2 - System arming with sensor exclusion..............PAG. 04 2.3 - Passive arming......................PAG. 04 2.4 - Arming delay......................PAG.
  • Page 3: Introductory Note

    2.0 - OPERATING INSTRUCTIONS 2.1 - SYSTEM TOTAL ARMING Press the vehicle original remote control lock button or button “1” on a Gemini remote control. If the optical/acoustic signals have been enabled, arming will be confirmed by 1 flash of the turn indicators and 1 Beep.
  • Page 4: Passive Arming

    You must touch the override key to its receptacle. Disarming via an optional Gemini remote control: Pressing button “2” on a Gemini remote control will simultaneously disarm the alarm and disable the engine immobilizer. If an alarm event has occurred while you were away from your vehicle, it will be signaled, when you disarm the sytem, by 5 siren chirps and 5 flashes of the turn indicators.
  • Page 5: Alarm Memory

    2.9 - ALARM MEMORY The LED memory allows to identify the last alarm event signaled by 5 siren chirps and 5 turn indicator flashes when the system is disarmed. Turn ignition key “ON”. The status LED will flash according to the last alarm detected prior to disarming (see table below).
  • Page 6: Optional Devices And Battery Replacement

    2.0 - FUNZIONAMENTO TELECOMANDO E SOSTITUZIONE BATTERIA 3.0 - OPTIONAL DEVICES AND BATTERY REPLACEMENT Remote controls have a low charge battery indicator that gives early warning to avoid malfunctioning. When the batteries are fully charged the LED shows a steady light at the press of a button while, if the batteries are low, the LED blinks.
  • Page 7: Rfid Transponder - 908

    3.3 - RFID TRANSPONDER - 908 to disable the engine immobilizer. To activate the transponder simply presss the button and keep it pressed for at least 4 sec. The LED turns ON steady when the transponder is activated. Release the button. The LED will flash everytime data is transmitted.
  • Page 8: Installer Manual

    ----- - 7 - Engine immobilizer BLACK marked “H” - 8 - Turn indicators positive output ORANGE For more complete information regarding connections, refer to the supported vehicle models installation instructions at www.gemini-alarm.com private area). PAGE 08 - INSTALLER MANUAL...
  • Page 9: Wiring Diagram

    5.0 - WIRING DIAGRAM Before carrying out electrical connections, disconnect the battery negative terminal and reconnect again after Connection to completion. supplied siren TOUCH KEY Green Brown Black BLACK marked “R” GREEN-BLACK POSITIVE Negative input - External sensors Battery GREEN-BROWN Positive/negative input - Door switches BLACK marked “M”...
  • Page 10: Connections To Arm/Disarm The System

    - CONNECTIONS TO ARM/DISARM THE SYSTEM 932IT alarm system can operate in various modes according to the vehicle on which it is installed and the available connections. The alarm system can be managed via the vehicle CAN BUS line and operate in combination with the CAN signals, with the turn indicators flashes and/or the door lock motor unit.
  • Page 11: Vehicle Code Programming

    Up-to-date information on supported vehicle models can be found in the private area of our website: www.gemini-alarm.com. The system has an indicator LED that signals any wrong vehicle code inserted. The code must range between 100 and 235 otherwise the LED on the unit blinks repeatedly and the procedure is interrupted.
  • Page 12: System Programming

    ” of arming/disarming optical signals Enabled Exclusion “ ” of arming/disarming acoustic signals Enabled System passive arming Disabled For Gemini only: Turn ignition key ----- Door input - positive Disabled Optical pulse signals (Hazard) Enabled For Gemini only: Turn ignition key ----- A lack of power during electrical system maintenance, will not affect the programming.
  • Page 13: Passive Arming

    8.3 - PASSIVE ARMING This function arms the system 60 sec. after ignition is switched OFF and the last door is opened and closed. If a door is opened during this lapse of time, the procedure is interrupted; it resumes when the door is closed.
  • Page 14: Adding New Devices

    Turn ignition key “OFF” and then back “ON” to disable the function. A Bop confirms the operation OFF-ON The LED flashes according to the selected function (from 1 to 7). Touch the key once to its receptacle to enable the function. A Beep confirms the operation Beep The LED flashes according to the selected...
  • Page 15: Deleting Programmed Devices

    • The system is ready to receive the device codes. • Depending on which device is to be stored in memory, either press one of the buttons on the remote control, touch the key to its receptacle have the transponder transmit, make the magnetic contact transmit (bring contact and magnet together and then move apart) press the button on the opening detector or make the infrared sensor transmit (see sensor instructions).
  • Page 16: Ultrasonic Volumetric Protection

    ULTRASONIC VOLUMETRIC PROTECTION 12.1 CONNECTIONS AND POSITIONING • Insert the WHITE connector in the “W” socket. • Insert the RED connector in the “R” socket. • Install the ultrasonic sensors on the top part of the windshield internal pillars, away from the air vents and point them towards the center of the rear window 12.2 - SENSOR ADJUSTMENT...
  • Page 17: Technical Specifications

    14.0 - TECHNICAL SPECIFICATIONS Power supply 12 Vdc Current absorption @ 12Vdc with system armed and LED flashing 15mA Working range temperature -30°C to +70°C Turn indicators relay contact capacity 8A @ 20°C Engine immobilizer relay contact capacity 8A @ 20°C Alarm cycle duration 30 sec.
