Function Codes for MicroLogix 1400 Series B Controllers
Message Function
Type Code
Request 14 (0x0E)
Request 15 (0x0F)
Request 16 (0x10)
Request 17 (0x11)
Request 18 (0x12)
Request 19 (0x13)
Request 20 (0x14)
Request 21 (0x15)
Request 22 (0x16)
Request 23 (0x17)
Request 24 (0x18)
Request 25 (0x19)
Request 26 (0x1A)
Request 27 (0x1B)
Request 28 (0x1C)
Request 29 (0x1D)
Request 30 (0x1E)
Request 31 (0x1F)
Request 32 (0x20)
Request 33 (0x21)
34 (0x22) to
128 (0x80)
Response 129 (0x81)
Response 130 (0x82)
Response 131 (0x83)
132 (0x84) to
255 (0xFF)

Implementation Table

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Name
FC_WARM_RESTART
FC_INITIALIZE_DATA
FC_INITIALIZE_APPL
FC_START_APPL
FC_STOP_APPL
FC_SAVE_CONFIG
FC_ENABLE_UNSOLICITED
FC_DISABLE_UNSOLICITED
FC_ASSIGN_CLASS
FC_DELAY_MEASURE
FC_RECORD_CURRENT_TIME
FC_OPEN_FILE
FC_CLOSE_FILE
FC_DELETE_FILE
FC_GET_FILE_INFO
FC_AUTHENTICATE_FILE
FC_ABORT_FILE
FC_ACTIVATE_CONFIG
FC_AUTHENTICATE_REQ
FC_AUTHENTICATE_ERR
FC_RESPONSE
FC_UNSOLICITED_RESPONSE
FC_AUTHENTICATE_RESP
MicroLogix 1400 supports DNP3 Certification Subset Level 2.
The implementation table in this section identifies which object groups and
variations, function codes and qualifiers the device supports in both requests and
responses. The Request and Response columns identify all requests and responses
MicroLogix 1400 Distributed Network Protocol (DNP3)
MicroLogix Description
1400 Support
No MicroLogix 1400 parses
No Obsolete
Yes MicroLogix 1400 parses. Clears fault and changes the
controller mode to Remote Program. See Starting and
Stopping User Programs (Mode Change) via DNP3 Network on
page 318.
Yes MicroLogix 1400 parses. Clears fault and changes the
controller mode to Remote Run. See Starting and Stopping
User Programs (Mode Change) via DNP3 Network on page
318.
Yes MicroLogix 1400 parses. Changes the controller mode to
Remote Program. See Starting and Stopping User Programs
(Mode Change) via DNP3 Network on page 318.
No Deprecated.
Yes MicroLogix 1400 parses
Yes MicroLogix 1400 parses
No
Yes MicroLogix 1400 parses. Used for non-LAN
No MicroLogix 1400 parses.Used for LAN
Yes MicroLogix 1400 parses
Yes MicroLogix 1400 parses
Yes MicroLogix 1400 parses
No MicroLogix 1400 parses
Yes MicroLogix 1400 parses
No MicroLogix 1400 parses
No MicroLogix 1400 parses
No MicroLogix 1400 parses
No MicroLogix 1400 parses
No Reserved.
Yes MicroLogix 1400 sends
Yes MicroLogix 1400 sends
No MicroLogix 1400 sends
No Reserved.
Appendix F
337
