Appendix H
System Loading and Heat Dissipation
Heat Dissipation
1762-OB8
1762-OB16
1762-OB32T
1762-OF4
1762-OV32T
1762-OW8
1762-OW16
1762-OX6I
1762-IQ8OW6
Add Sub-Totals to determine Heat Dissipation
(1) Only applicable to Series B I/O modules.
372
1.6 W x number of modules
2.9 W x number of modules
3.4 W x number of modules
3.8 W x number of modules
2.7 W x number of modules
2.9 W x number of modules
(1)
6.1 W
x number of modules
2.8 W x number of modules
4.4 W x number of modules
1.6 W x _________
2.9 W x _________
3.4 W x _________
3.8 W x _________
2.7 W x _________
2.9 W x _________
(1)
6.1 W
x _________
2.8 W x _________
4.4 W x _________
Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
W
W
W
W
W
W
W
W
W
W
