INSTALLING THE AILERONS

1. Test fit the ailerons to the wing with the hinges.
If the hinges don't remain centered, stick a pin
through the middle of the hinge to hold it in
position.
Main Wing
Aileron
Apply instant glue (CA glue, super glue).
TEMPORARY PIN
TO KEEP HINGE
CENTERED
2. Apply six drops of thin CA to the top and bottom
of each hinge. Do not use CA accelerator. After
the CA has fully hardened, test the hinges by
pulling on the aileron.
< Bottom view >
Make certain the hinges are adequately secured with glue. If
they come loose in flight accidents may result.
Secure nylon hinges with instant glue, being careful
not to glue the wing and airleron together.
Align the center line of main wing with aileron.
2
STREGA
Flap
