INTRODUCTION: SPECIFICATIONS
Chapter 3
3
3.1

Current Ratings

710-03261-00D

Specifications

(At 1000 m.)
Two starts per hour
3.5-15 : 1785
40 °C 50 °C
MVS0080 96 91
MVS0159 190 177
MVS0230 282 261
MVS0321 393 363
Three starts per hour
4.0-20 : 1180
40 °C 50 °C
MVS0080 73
146
MVS0159
MVS0230 207
MVS0321 288
Four starts per hour
4.0-20 : 880
40 °C 50 °C
MVS0080 68
MVS0159 136
MVS0230 188
MVS0321 262
AC53b Utilisation Category Format
80 A: AC-53b 4-20 : 1780
Start Current
Starter Current Rating
Starter Current Rating: The full load current rating of the soft starter given the
parameters detailed in the remaining sections of the utilisation code.
Start Current: The maximum available start current given the parameters detailed
in the remaining sections of the utilisation code.
Start Time: The maximum available start time given the parameters detailed in the
remaining sections of the utilisation code.
Off Time: The minimum allowable time between the end of one start and the
beginning of the next start given the parameters detailed in the remaining sections
of the utilisation code.
Contact your local supplier for ratings under operating conditions not covered by
the above ratings charts.
4.0-20 : 1780 4.0-30 : 1770
40 °C 50 °C 40 °C
80 74 72
159 147 143
230 213 201
321 296 279
4.0-30 : 1170
40 °C 50 °C
68 65 60
135 129 119
190 175 162
265 244 225
4.0-30 : 870
40 °C 50 °C
63 59 54
125 117 108
173 157 144
241 218 200
Off Time
(seconds)
Start Time
(seconds)
(multiple of FLC)
(amperes)
6
5.0-30 : 1770 5.0-60 : 1740
50 °C 40 °C 50 °C 40 °C
66 59 55 46
132 117 109 91
185 165 152 121
257 229 211 168
5.0-30 : 1170 5.0-60 : 1140
40 °C 50 °C 40 °C
53 49 40
106 98 79
144 132 101
200 184 141
5.0-30 : 870 5.0-60 : 840
40 °C 50 °C 40 °C
48 45 35
96 89 70
129 118 88
179 164 122
50 °C
42
84
111
154
50 °C
37
73
93
129
50 °C
33
65
81
112
MVS Series
