MVS Series
To navigate through the Commissioning Menu:
•
to scroll the next or previous item, press the ▲ or ▼ button
•
to open an item for viewing, press the ► button
•
to return to the previous level, press the ◄ button
•
to close the Commissioning Menu, press the < SETUP TOOLS > button.
NOTE
The Commissioning Menu is only available if the Programming Menu is
unlocked (parameter 20-B Adjustment Lock is set to Off).
Thermal Model Reset
The soft starter's advanced thermal modelling software monitors the motor's
performance during each start and throughout the running cycle. This allows the
soft starter to calculate the motor's temperature and ability to start successfully at
any time.
The soft starter's thermal model can be reset if required.
Reset Thermal Models
In order to reset the thermal model, press the ► button. At the confirmation
prompt, press < STORE > to confirm or < UNDO > to cancel the action. Cancelling
the action returns to the Commissioning Menu.
When the thermal model has been reset, the screen will briefly display a
confirmation message, then return to the previous screen.
Reset Thermal Models
Reset
Parameter Archive
The parameter archive menu allows users to:
•
restore the MVS to factory default settings
•
save the current parameter settings to an internal file
•
reload parameter settings from an internal file
The MVS can store two separate user-defined files.
1. To select a parameter archive function, scroll to the Parameter Archive screen
in the Commissioning Menu then press the ► button.
Parameter Archive
2. Use the ▼ button to select the desired function.
Load Defaults
The options are:
•
Load defaults
•
Load user set 1
•
Load user set 2
•
Save user set 1
•
Save user set 2
3. When the screen shows the required function, press the ► button. The MVS
will prompt for confirmation.
OPERATION: USER INTERFACE
Reset >
Load/Save >
Load >
