Power Factor Correction; Line Inductors; Transient/ Overvoltage Protection - AuCom MVS0080 Product Manual

5.6

Power Factor Correction

5.7

Line Inductors

5.8

Transient/ Overvoltage Protection

MVS Series
Fuse ratings:
Motor Rated FLC 4.0-20:1780
70 A
100 A
130 A
150 A
170 A
200 A
230 A
300 A
390 A
Fuse type code formats:
Ferraz
Bussmann
rr = R rating of the fuse
x = physical format of the fuse (select according to installation requirements)
Examples:
6R fuse for 2.3 kV: A240R6R or JCK-A-6R
12R fuse for 3.3 kV: A480R12R-1 or JCL-B-12R
18R fuse for 6.6 kV: A072B1DARO-18R or JCR-B-18R
Power factor correction capacitors should be selected based on the motor data and
the required final power factor.
If power factor correction capacitors are being used, select a contactor according to
the required kVAr. The contactor must be connected on the supply side of the soft
starter. The power factor correction capacitor contactor coil is associated with
output terminals 33, 34 of the soft starter's power interface PCB.
To ensure that the potentially dangerous medium voltage area is isolated from the
low voltage control area, power is supplied to the power factor correction capacitor
contactor coil from the control voltage terminal block (refer to Diagram 4: Internal
Wiring on page 21).
NOTE
The capacitor bank must be fed from the supply side of the soft starter.
Line inductors are required if the cable run between the soft starter and the motor
is greater than 200 m. Line inductors should be installed outside the panel,
between the soft starter output (terminals T1, T2, T3) and the motor. Contact your
local supplier for selection details.
Overvoltage protection should be installed if there is a risk of high transients at the
installation. If required, use the optional Overvoltage Protection Kit. Contact your
local supplier for details.
INSTALLATION: POWER CIRCUITS
4.0-30:1770
4R 4R
5R 5R
6R 6R
9R 9R
9R 9R
12R 12R
12R 12R
18R 18R
18R 18R
System Voltage System Voltage
2.3 kV
A240Rrr
JCK-x-rr
17
5.0-30:1770
4R
6R
9R
9R
12R
12R
18R
18R
24R
System Voltage
3.3 ~ 4.2 kV 6 ~ 7.2 kV
A480Rrr-1 A072xxDxRO-rr
JCL-x-rr
5.0-60:1740
5R
9R
9R
12R
12R
18R
18R
24R
24R
JCR-x-rr
710-03261-00D
