ETC source four Assembly Instructions Manual page 10

3
(4 required)
8A
1
10
19°, 26°, 36°, and 50° lens tubes
Reference
Number
1
2
3
4
5
6
7
8
8A
9
10
11
12
13
14
15
16
17
11
(4 required)
13
14,15,16,17
9
12
(4 required)
Part Description
Number
7060A3050 Lens holder, left casting, painted
7060A3051 Lens holder, right casting, painted
7060A4009 Bushing, guide
7060A4012 Pad lens support - asphere
Pad lens support - meniscus set
7060A4002 Aspheric lens, 19°
7060A4001 Aspheric lens, 26°
7060A4004 Aspheric lens, 50°
7060A4020 Meniscus lens, 36° set, front
7060A4021 Bi-convex lens, 36° set, rear
7060A3079 Clip, gel retainer, 90° bend
HW750 Spring, retainer
HW391 Screw, PHMS, 8-32 x 3/4, black zinc
HW370 Nut, Ny-Lok, 8/32, black zinc
HW534 Nut, hex, 1/4-20, black zinc
7060A4033 19° lens tube label
7060A4034 26° lens tube label
7060A4035 36° lens tube label
7060A4036 50° lens tube label
2
5
6
7
8
4
(4 required for 19°, 26°, 50° lens)
(8 required for 36° lens set)
Note: Each lens is different.
Do not interchange. i.e., do not
place a 19° lens in a 26° slot.
10
Place side of lens
with painted dot
toward front of
fixture.
19° (6x16)
Red dot
26° (6x12)
Black dot
50° (4.5x6)
Yellow dot
2/96
36° (6x9)
No dots
Quantity
Required
1
1
4
4
8
1
1
1
1
1
1
1
4
4
1
1
1
1
1
