INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
120517-20
Visit www.townandcountry.com for the most recent version of this manual
TCWS.54DST
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART# TCWS.54NGST04D
For TCWS.54DST
Series D
Fireplaces
TCWS.54NGST04D
5056.425183D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCWS.54NGST04D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TCWS.54NGST04D

Summary of Contents for Town & Country Fireplaces TCWS.54NGST04D

  • Page 1 Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TCWS.54DST TRANQUILITY BURNER KIT INSTRUCTIONS PART# TCWS.54NGST04D For TCWS.54DST Series D Fireplaces TCWS.54NGST04D 5056.425183D 120517-20 Visit www.townandcountry.com for the most recent version of this manual...

  • Page 2: Contents Of Package

    Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TCWS.54DST TRANQUILITY BURNER KIT INSTRUCTIONS PART# TCWS.54NGST04D For TCWS.54DST Series D Fireplaces 280417-16 TCWS.54NGST04D 5056.425183D Visit www.townandcountry.com for the most recent version of this manual Manual &...
  • Page 3 Tranquility Burner Installation NOTE: For purposes of clarity, the “Front” of the fireplace shall be the side which has access to the electrical connection compartment cover, the connection to the gas valve and the side which places the control compartment cover and the coaxial vent located on top of the fireplace to your left. Note: If converting fireplace from natural gas to propane gas, please refer to “Propane Conversion”...
  • Page 4 Figure 5: Securing outer leg on left hand side secondary Figure 6: Securing outer leg on right hand side secondary oor panel. oor panel. 4. Place one of the two outer legs on the left hand secondary oor panel. Be sure to secure this leg in the orientation shown and secure to the second set of holes in from the left side (Figure 5).
  • Page 5 NOTE: Check air shutter for correct fuel setting before proceeding any further. Both burner shutters are to be set the same. Fully closed for NATURAL GAS and 3/16” open for LIQUID PROPANE. CAUTION: The burners should be tightly butted up against each other at the center to ensure correct operation.
  • Page 6 Install Side Panels Side panel retainer clips Figure 11: Side panel retainer clips location. Figure 12: Side panel. 11. If not already removed, remove the side panel retainer clips located in the upper rebox (Figure 11). There are two clips at each end of the rebox. 12.
  • Page 7 Figure 15: Burners and side panels in place. Figure 16: Burner tray in place. 13. With the side panels in place, install the burner tray cover and secure with six screws onto the legs. There is a opening for the pilot assembly in the burner tray (Figure 16). Installing sand and decorative rocks Figure 17: Brushing the sand smooth in the burner tray.
  • Page 8 Figure 18: Bottom of rock with arrow. Figure 19: Single set of rocks. 15. Position yourself at the “REAR” of the replace - as a reminder, the front is the side which puts the electrical connection compartment and the exhaust ue on your left hand side. Each rock has a slot in it’s base and is marked with a letter and an arrow (Figure 18).
  • Page 9 Figure 23: Rock D. Figure 22: Rock C. Figure 24: Rock E. Figure 25: Rock F. Figure 26: Rock G. Figure 27: Rock H. 5056.425183D TCWS.54NGST04D_120517-20...
  • Page 10 Figure 28: Rock J. Figure 29: Rock A left side. Figure 31: Exposed pilot assembly. Figure 30: Rock B left side. Figure 32: Pilot rock. Figure 33: Pilot rock in place. 5056.425183D TCWS.54NGST04D_120517-20...
  • Page 11 17. Pilot rock. Once all rocks have been positioned, a hollow pilot rock (Figure 32) will cover the pilot assembly. Place it so that its side opening allows the pilot ame to extend to the burners (Figure 33). 18. Place the two edge panels along the length of the replace (Figure 34) with the short side facing toward the center (Figure 35).

  • Page 12: Propane Conversion

    Propane Conversion If this unit is to be used on propane convert as follows using the components supplied with the pro- pane gas conversion kit. Propane conversion kit part number is TCWS.54DSTLPKIT. Note: Factory supplied components must be used to ensure correct input. After conversion con rm proper manifold pressure.
  • Page 13 3/16” Open for Propane Gas Fully closed for Natural Gas Figure 37: Shutter gap settings. 3. Loosen the primary air shutter screw on each burner, open the shutter to give a gap of 3/16” and re- tighten (Figure 37). Band in natural gas position Figure 38: Pilot in natural gas position.
  • Page 14 Accessing the gas valve for conversion Grommet Figure 41: Wires through grommet. 1. If installed, remove the burner media (rocks, glass, etc.) from the burner tray. Remove the edge panels, burner tray, left hand burner, left hand side panel, release pilot assembly from center leg and remove left hand secondary oor panel.
  • Page 15 Figure 43: Small plate lifted to proved access to connector. 3. Remove screws for the small cover panel and lift the panel and exible gas lines enough to be able to get your hand underneath it (Figure 43). 4. Locate the stepper (Figure 44) and follow its wires back to its electrical connection and discon- nect (Figure 45).
  • Page 16 Figure 45: Stepper connector location. 7. Once conversion is complete, ll out and af x the gas conversion label (Figure 46) to the inside of the gas valve inside of control box where it will not be affected by the heat of the rebox. Figure 46: Propane Conversion Label.

  • Page 17: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. Pressure test extension Manifold...

  • Page 18: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For LP See “Shutter gap settings.” on page 13. Some adjust- ment may be necessary to obtain desired ame and to eliminate carbon deposits.

  • Page 19: Replacement Parts

    Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART #1 TRANQUILITY BURNER KIT ....TCWS.54NGST04D 22150053 #2 PEBBLE ASSEMBLY(1 Box)......TCRP.TRANQA 80001272 #3 SAND (1 Bag) ..........TC42.SAND34 80000486 #4 PILOT ROCK ........TCRP.TQTRIMROCKS 80000559 NOT SHOWN KIT CONTENTS: 5056.425183D...
  • Page 20 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
