INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the replace and should be
kept together. Refer to the Installation and Operating Instructions for
proper gas supply, safety requirements and operating instructions
Visit www. townandcountryfi replaces.net for the most recent version of this manual
090117-16
TC42
TRANQUILITY
BURNER KIT
INSTALLATION
INSTRUCTIONS
PART# TC42.
NG04D
For TC42 Series D
Fireplaces
TC42_NG04D
5056.426D4
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC42.NG04D
Summary of Contents for Town & Country Fireplaces TC42.NG04D
- Page 1 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. These instructions are supplementary to the Installation and Operating Instructions supplied with the replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions TC42 TRANQUILITY...
-
Page 2: Contents Of Package
Contents of Package Burner assembly Panel, base Pebble assembly Cover, right side Cover, left side 3.4 lbs sand Bag tapered plugs Figure 1: Tranquility burner kit package contents. Tranquility Burner Installation If converting to propane see conversion instructions on page 10 before proceeding. NOTE: Plug the 4 vacant holes in the bottom of the firebox with 1/2”... - Page 3 Figure 5: Lower rear panel. 3. Position lower rear porcelain panel centered at the rear of the rebox. Place burner assembly into the rebox against the rear panel (Figure 5). Figure 6: Panel clips. 4. Place panel clips under both rear corners of the base plate as shown in Figure 6 (approx. 3” from rear panel).
- Page 4 Figure 7: Gas and pilot supply tubes. 5. Attach the manifold supply tube and the pilot supply tube to the bulk head ttings and tighten (Figure 7). Ensure that there are no leaks. Ignition and sensor wires Bulkhead plate Figure 8: Ignition and sensor wires routing. 6.
- Page 5 Flame sensor wire (white) Ignition wire (red) Interface module Figure 9: Interface module. 7. Attach the ignition and sensor wires to the module (Figure 9). Figure 10: Right side panel installation. 8. Remove panel retainer from upper heat shield. Install right porcelain panel tilting in from front corner (Figure 10).
- Page 6 Figure 11: Inserting side panel into panel clip. 9. Slip the side panels into the panel clip as shown in Figure 11. Figure 12: Upper rear panel installation. 10. Position upper rear panel on the top of the lower rear panel and behind the right panel. While supporting the upper rear panel install and secure left porcelain panel in the same manner as the right panel (Figure 12) Secure with the previously removed panel retainer.
- Page 7 Figure 13: Securing sliding cover. 11. Slide covers out and attach to base with one screw each (Figure 13). Figure 14: Inserting tapered plugs. 12. Insert tapered plugs into raised burner ports to prevent sand from entering ports (Figure 14). TC42_NG04D_090117-16 5056.426D4...
- Page 8 Figure 15: Adding sand to tray. 13. Place sand in tray. Brush sand smooth and level to just below top of raised burner ports (Figure 15). 14. Gently blow excess sand from around ports. 15. Remove tapered plugs from ports. Figure 16: Positioning pebble assembly.
- Page 9 Figure 17: Trim rocks added to pebble assembly. 16. Remove pebble assembly from packaging by placing hand on top and tipping upside down. Gently place pebble assembly onto sand base using pins to locate position (Figure 16). 17. Place trim rocks at desired locations in the sand around the pebble assembly. Install glass door. Unit is ready for lighting.
-
Page 10: Propane Conversion
Propane Conversion If the unit is to be used with propane gas, convert the fireplace from natural gas as follows using the components supplied with this burner kit. For complete valve installation instruc- tions , refer to the instruction book included in the SIT conversion kit. Note: Factory supplied components must be used to ensure correct input. -
Page 11: Securing Screw
Securing screw Air shutter opening Figure 20: Adjusting the air shutter. Figure 21: Pilot assembly. 4. Loosen the primary air shutter screw (Figure 20), open shutter fully and re-tighten screw. 5. Remove the 2 screws hold- ing the pilot assembly in place with a stubby screw- driver (Figure 21). -
Page 12: Burner Flame Adjustment
Burner Flame Adjustment The air shutter on the burner inlet tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired ame and to eliminate carbon deposits. -
Page 13: Replacement Parts
Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 TRANQUILITY BURNER KIT ....TC42.NG04C #5 PILOT ASSEMBLY, CONVERTIBLE ..TCRP.5005025 #2 PEBBLE ASSEMBLY ........TC42.9499 #6 ORIFICE, NATURAL GAS (#25) .......5022.12 #3 MAIN SUPPLY TUBE ........5019.223 #7 PROPANE CONVERSION KIT ....TC42.LPCE01 #4 PILOT TUBE ..........5019.225 #8 SAND ........... - Page 14 TC42_NG04D_090117-16 5056.426D4...
- Page 15 TC42_NG04D_090117-16 5056.426D4...
- Page 16 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8...
