INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury
or death.
FOR YOUR SAFETY
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
What To Do If You Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a
certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Visit www.townandcountryfireplaces.com for the most recent version of this manual
270619-48
INSTALLATION MANUAL
TCWS54DST2
TCWS54D
SEE THRU - Version 2
INSTALLATION
MANUAL
MODEL TCWS54DST
SERIES: D
DIRECT VENTED
DECORATIVE GAS
APPLIANCE
This is a decorative product and
is not intended to be used as a
heating appliance.
100001139-50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D Series and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces D Series

Summary of Contents for Town & Country Fireplaces D Series

  • Page 1 INSTALLATION MANUAL INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY Installation and service must be performed by TCWS54D...

  • Page 2: Table Of Contents

    Table of Contents TCVT.PV Power Vent Installation ..........22 Caution ..................3 Venting Configurations ............23 Safety ..................3 Venting Length ................ 23 Important Note for the Commonwealth of Massachusetts ..4 Fireplace Dimensions ..............5 Minimum Vent Length Chart ............ 24 Minimum Clearances to Combustible Material ......

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country fireplace without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous. This appliance and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions 12 11/16" 41 1/4" 18 5/8" 24 7/16" 33 13/16" 11 3/4" 11 9/16" 54 7/16" 5 11/16" 69 9/16" 62 3/8" Figure 1: TCWS54D_ST Fireplace dimensions. Minimum Clearances to Combustible Material NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATERI- FINISH WALL ABOVE STANDOFFS AL, ELECTRICAL WIRING OR GAS PLUMBING IN...

  • Page 6: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the local codes or, in the absence of local codes, current CSA B149.1 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1/NFPA 54 (in the USA).

  • Page 7: Standoffs

    Standoffs The framing kit, once assembled and attached, act as the top and side standoffs Figure 7: Assembled frame as stand-offs. Locating The Fireplace In planning the installation for the fireplace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed.

  • Page 8: Framing And Finishing

    Framing and Finishing Note: The fireplace should be in place non-combustible material. Assemble the Chase Insulation: and venting installed before framing in framing kit as per the instructions on pages When installing this fireplace against a or building an enclosure around the unit. 10 –...
  • Page 9 NON-COMBUSTIBLE BOARD DETAIL If finishing the wall above the unit with paint, the framing kit shipped with the unit should be discarded. Use full sheets of calcium silicate board or NON-COMBUSTIBLE equivalent and full length metal studs BOARD ONLY IN to finish and frame around the unit.
  • Page 10 It is important to note that any nishing material used must not interfere with the glass door being able to open in the event of ignition of excess gas buildup. Figure 14: Recessed installation details. 100001139 TCWS54DST2_270619-48...

  • Page 11: Steel Stud Framing Kit

    Steel Stud Framing Kit BEND OUT FRAMING TABS TO FRONT SCREW INTO SIDE FRONT VIEW (slightly angled) Figure 15: Framing kit components. Each Kit Contains: Item Description Qty. Item Description Qty. SCREW, WAFER #8 x 1/2 INNER CROSS BRACE (Not shown) 56 5/8 L STUD, CENTER 25”...
  • Page 12 NOTE: Sheet metal parts have sharp edges, use caution when handling. Frame Assembly - Note: 2 identical frames will be assembled. One for each side of the fireplace (See Figure 15) 1. On a flat surface, place 2 upper/lower studs (#4). One is to become the top-most horizontal stud and one is to become the bottom-most horizontal stud.

  • Page 13: Fixed Lintel

    Secure to Existing Framing • Bend out the tabs 90 degrees before inserting the unit into its framed housing. • Secure the frame assembly to the wood frame through the tabs (Figure 17). Install Non-Combustible Board (not supplied) • Use drywall screws to install the non-combustible board. Figure 16: Framing bracket positioning.
  • Page 14 Flanged edge Hemmed edge Screen Figure 19: Optional lintel edge. Figure 20: Safety barrier screen. 1. The fixed lintel has two orientations, a flanged edge and a hemmed edge (Figure 19). The lintel comes factory installed with the flange edge out. If the desired edge is different from the factory setting, use the following steps to change the lintel edge.

  • Page 15: Fireplace Facing Allowance

    Fireplace Facing Allowance This fireplace is designed to finish either flush with the facing material or can be installed with a 4 1/2 inch recess. “Figure 12: Non - combustible recessed NON-COMBUSTIBLE NON-COMBUSTIBLE FINISH MATERIAL installation detail.” on page 9. BUILDING MATERIAL MAY NOT EXTEND PAST THIS POINT The fireplace can accommodate facing...

  • Page 16: Electrical

    Electrical NOTE: For purposes of clarity, the “Front” of the fireplace shall be the side which has access to the electrical connection compartment cover, the connection to the gas valve and the side which places the control compartment cover and the coaxial vent located on top of the fireplace to your left.
  • Page 17 Wall switch connection to interface board Figure 28: Interface board connection for wall switch. Figure 27: Power vent switch. 4. Connect the cable for the wall switch / Home automation to the connector just forward of the power vent switch (Figure 28). 5.
  • Page 18 Figure 31: Do not install batteries in this wall switch. 8. Do not install batteries into the wall switch (Figure 31). Battery holder must remain empty. 9. If not already installed, install the burner using the instructions supplied with the burner kit. 10.

  • Page 19: Wall Switch And Remote Control

    Wall Switch and Remote Control Note: The wall switch must not have batteries installed in it. The batteries are for back up in case of a power outage. This fireplace must not operate with a battery back up. Figure 32: Wall switch. Figure 33: Wall switch with no batteries.

  • Page 20: Home Automation

    Home Automation The home automation feature supplied with this fireplace is capable of controlling the flame and light on/off function with the use of a dry contact relay common to home automation systems. Furthermore, the flame and light level may be modulated from high to low using the 0 - 10 volt analog output available on most home automation systems.

  • Page 21: Gas Supply

    Gas Supply Servicing of the appliance can be performed from inside the unit and through the access panel located in the firebox bottom. Caution: The gas line should be installed by a qualified service person in accordance with all building codes. This section is intended as a guide for qualified technicians installing this appliance.

  • Page 22: Venting

    Venting The TCWS54STD2 fireplace must be power vented. There are two options for terminating the venting for this fireplace: This fireplace can only be wall terminated using the TCVT. PV1.25 or TCVT.PV7.110 power vent kit. Please see the instructions supplied with the power vent kit for installation details. For roof termination, power vent TCVT.PVCV must be used.

  • Page 23: Venting Configurations

    Venting Configurations chimney minimum 1½” clearance to combustable surfaces power vent (vertical) VENTING CONFIGURATIONS from vent pipe Maximum total vent length is 110ft plus six 90-degree elbows or combination of other elbows equaling 90-degrees, with a minimum venting - 3’ maximum 66 foot vertical rise.

  • Page 24: Minimum Vent Length Chart

    Minimum Vent Length Chart Minimum Rise from Pipe Length Min. Pipe Length Floor to Flue Center TCWS54DST 49” 0” 3 feet 61” 12” 2 feet 73” 24” 1 foot Figure 38: Horizontal rise run adapter. Vent Terminal Minimum Clearances FIXED CLOSED OPEN- FIXED...

  • Page 25: Venting Components

    Venting Components SIMPSON DURAVENT COMPONENTS SECURE VENT COMPONENTS Number Description Number Description SV5L6 6” Pipe Length 1208 6” Pipe Length SV5L12 12” Pipe Length 1207 9” Pipe Length SV5L24 24” Pipe Length 1206 12” Pipe Length SV5L36 36” Pipe Length 1204 24”...

  • Page 26: Vent Pipe Sealant

    Vent Pipe Sealant Approved “high temp” VENT PIPE self-adhesive tape (supplied) Figure 40: Sealing vent with tape. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press firmly in place. Inner pipe does not need to be sealed.

  • Page 27: Propane Conversion

    Propane Conversion If this unit is to be used on propane convert as follows using the components supplied with the propane gas conversion kit. Propane conversion kit part number is TCWS.54DSTLPKIT. Note: Factory supplied components must be used to ensure correct input. After conversion confirm proper manifold pressure.
  • Page 28 TCWS.54DST Ori ce sizes: 3/16” Open for Propane Gas Natural Gas: 2.95 mm Propane Gas: 1.78 mm Figure 42: Orifice. 4. Using a 1/2” wrench, undo Figure 43: Shutter gap for propane. the natural gas burner orifices and replace with the propane gas orifices included in the conversion kit.
  • Page 29 7. Slide the pilot adjustment band over (Figure 46) and ensure that the hole in the orifice band is showing. 8. Remove access panel to gain access to the gas valve for propane conversion. 9. Once the pilot head is switched over to propane gas from natural gas, continue with the conversion...

  • Page 30: Accessing The Gas Valve For Conversion

    Accessing the gas valve for conversion Grommet Figure 47: Wires through grommet. CAUTION The gas supply and electrical power at the breaker shall be shut off before proceeding with the conversion. Consult the Burner Kit instruction manual for burner removal/installation. 1.
  • Page 31 Figure 49: Small plate lifted to provide access to connector. 3. Remove screws for the small cover panel and lift the panel and flexible gas lines enough to be able to get your hand underneath it (Figure 49). 4. Locate the stepper (Figure 50) and follow its wires back to its electrical connection and disconnect (Figure 51).
  • Page 32 Figure 51: Stepper connector location. 7. Once conversion is complete, fill out and affix the gas conversion label (Figure 52) to the inside of the control box where it will not be affected by the heat of the firebox. This appliance was converted to propane gas Kit Number 5052.52001-B Company...

  • Page 33: Gas Pressure Check Procedure

    Gas Pressure Check Procedure Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. 1.

  • Page 34: Firebox Panels Installation

    Firebox Panels Installation Retaining clip 1. Remove side panel securing tabs for both sides in upper firebox (Figure 55). 2. Place bottom of side panel in first then tip up into vertical position (Figure 56). Figure 55: Retaining clip. 3. Attach the side panel securing tabs previously removed.

  • Page 35: Finishing Touch Trim Kit Installation

    Finishing Touch Trim Kit Installation The trim kit includes two side pieces, a top piece, and a bottom meshed piece which will be placed onto the fireplace floor and the door. Installation 1. Begin by setting out the two side trim pieces and the top piece. Each of these three trim pieces require 2 small button magnets which are included with the trim pieces.
  • Page 36 Figure 63: Installing bottom trim. Figure 64: Bottom trim in place. 4. The meshed trim piece for the bottom rests on the floor and in the gap between the frame and the glass fireplace door (Figure 63 and Figure 64) Figure 65: Town &...

  • Page 37: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. For LP . Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits.

  • Page 38: Maintenance

    Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fireplace and its venting should be inspected at least once a year by a qualified service person.

  • Page 39: Replacement Parts - Tcws.54Dst

    Replacement Parts - TCWS.54DST (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #1 TCWS BODY ASSEMBLY ....TCWS.54CSTE *#5 FINISHING TOUCH TRIM KIT..TCRP.54WSTRIMKIT #2 GLASS ASSEMBLY (c/w gasket) ..GLAS.2062BASSY #6 ORIFICE (2pcs) ..........5021.332A #3 FRAMING KIT .......

  • Page 40: Replacement Parts - Tranquility Burner

    Replacement Parts - Tranquility Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. #1 TRANQUILITY BURNER KIT ..............TCWS.54NGST04D #2 PEBBLE ASSEMBLY(1 box) ..............TCRP.TRANQA #3 SAND (1 Bags) ...................TC42.SAND34 #4 PILOT ROCK, BLACK ................... 8421-A PILOT ROCK, GREY ..................... 8422-A NOT SHOWN Kit Contents Figure 70: Tranquility burner replaceable parts.

  • Page 41: Replacement Parts - Diamond Burner

    Replacement Parts - Diamond Burner (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. #1 DIAMOND BURNER ................TCWS.54NGST03D #2 GLASS MEDIA (1 - 5lb bag. 2 required) ............TCRP.501207 #3 LIGHT BULB ......................5033.713 NOT SHOWN Kit Contents Figure 71: Twilight diamond burner replaceable parts. TCWS54DST2 270619-48 100001139...

  • Page 42: Replacement Parts - Valve Control System

    Replacement Parts – Valve Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #4 TEST FITTING ..........5019.104 #1 CONTROL ASSEMBLY KIT ....TCCV.95755-B #2 BULKHEAD ASSEMBLY KIT ..... TCRP.8133 #5 WALL SWITCH ASSEMBLY KIT....TCRP.WSA #6 REMOTE TRANSMITTER ......

  • Page 43: Wiring Diagram

    Wiring Diagram TCWS54DST2 270619-48 100001139...

  • Page 44: Rating Label

    Rating Label NOTE: The Rating Label is located on a plate found in a slot between the left hand side lintel and the left hand side door frame. This plate is attached to the side casing with a cable. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À...
  • Page 45 TCWS54DST2 270619-48 100001139...
  • Page 46 100001139 TCWS54DST2_270619-48...
  • Page 47 TCWS54DST2 270619-48 100001139...
  • Page 48 © 2019 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountryfireplaces.com 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
