Audiovox Pursuit PRO-9675FT4 Owner's Manual

Pursuit series 4 button remote start security system with plug-in shock sensor & starter disable
Hide thumbs Also See for Pursuit PRO-9675FT4:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual
4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
FEATURES :
w 2 Four Button Programmable RF Transmitters
w Four Channel Code Learning Receiver (capable of accepting 4 transmitters)
w Anti Code Grabbing Technology
w Selectable Manual Override Mode
w Remote Panic in all modes
w Protected Valet/Override
w Remote Start Safety Control Switch
w Selectable Automatic Timed Start Mode
w User Programmable Manual Override Code
w 7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
w Intrusion Alert with Memory
w Audible Arm / Disarm / Defective Zone / Tamper Confirmation
w Instant Siren Activation All Entry Points
w Starter Disable When Armed
w True Last Door Arming
w Defective Zone By-Pass
w Active or Passive Arming Selectable
w Programmable Auto Lock On / Off
w Programmable Auto Unlock / Off/Drivers Door/All Doors
w Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
w Programmable Active or Passive Door Locks
w User Programmable Permanent Chirp Delete
w On Command RF Chirp Delete from Transmitter Or Selectable Through Software
w 6 Tone Multi Tone Siren
w Car Horn Activation for additional alarm response
w Additional Negative Trigger Input
w RF Inhibit with ignition on
w Parking Light Flasher
w Remote Keyless Entry With Optional Access Guard (must have power door locks)
w Illuminated Entry
w Plug In Dual Stage Shock Sensor
OPTIONS :
w Remote Trunk Release (must have electronic trunk release)
w Multiple Vehicle Capable
w Remote Power Window Roll Up
w Remote Garage Door Interface
CAUTION ! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
Model PRO-9675FT4
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for Audiovox Pursuit PRO-9675FT4

Summary of Contents for Audiovox Pursuit PRO-9675FT4

  • Page 1 CAUTION ! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if it is garaged. Model PRO-9675FT4 Owner's Manual...

  • Page 2: Arming The System - Active

    The system will now respond to that transmitter each time a button is pressed. For reference the transmitter packaged with your PRO-9675FT4 is shown below. ARMING THE SYSTEM - ACTIVE: 1. Turn the engine off, exit the vehicle, and close all doors, hood and trunk.

  • Page 3: Protection While The System Is Armed

    opened during the 30 second arming cycle, arming will be suspended. When all entry points are closed, the arming cycle will begin again. At the end of the 30 seconds, the parking lights will flash once, the siren will chirp once, and the dash mounted LED will begin to flash slowly confirming the system is armed.

  • Page 4: Silent Disarming

    SILENT DISARMING: 1. As you approach the vehicle, press and hold the Unlock button of your key chain transmitter for two seconds. The parking lights will flash twice, and the dash mounted LED will turn off confirming that the system is disarmed. The siren will not chirp. If you have the optional door lock/unlock circuit installed, the doors will unlock.
  • Page 5 3. To return to normal operation, press and release the pushbutton switch any time the ignition is on. NOTE : Always remember to return the vehicle to the valet off position. This will ensure that the vehicle remains protected at all times. MANUALLY OVERRIDING YOUR SYSTEM: USING THE VALET SWITCH MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmitter.

  • Page 6: Eliminating The Normal Arm/Disarm Chirps

    Custom Code Programming Example: To Change the code from the factory pre-assigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.

  • Page 7: Remote Panic Operation

    defective zone indicator will always operate. Since these are important warnings to you that something has happened, they cannot be eliminated. REMOTE PANIC OPERATION The Lock or Unlock button on your keychain transmitter also functions as a panic switch for use in emergency situations.

  • Page 8: Operating On Automatic Start Up Timer Mode

    programming set up by your installation center. When you arrive at your vehicle, disarm the alarm system by pressing and releasing the unlock/disarm button of your keychain transmitter. Enter the vehicle and turn the ignition key to the on position. CAUTION ! Do not turn the key to the start position.
  • Page 9 Remote Window Closure o Remote Garage Door Interface o 2nd Vehicle Equipped With Similar Audiovox Products If your vehicle is not equipped with an electronic trunk release switch, or other option listed, this feature may have been connected to another accessory. Please ask your dealer for further information.
  • Page 10 3 FLASH CONTINUOUS FLASH REMOTE START SIREN INDICATIONS 1 LONG/1SHORT REMOTE START PARKING LAMP INDICATIONS 1 FLASH CONTINUOUS FLASH © 2000 Audiovox Electronics Corporation, Hauppauge, NY 11788 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2 INTRUSION ZONE 1...
