Model PRO9644i 3 Button Remote Security System with Dual Stage Shock Sensor Owner's Guide Table Of Contents: Features Page 2 Options Page 2 Your "Code Hopping" Transmitters Page 3 Arming the System - Active Page 3 - 4 Arming the System - Passive...
IMPORTANT! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.
YOUR " CODE HOPPING" TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and retransmit at a later time to disarm your system.
SILENT ARMING - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid. 2. Press and hold the Lock button on the keychain transmitter for 2 seconds. Dash mounted LED begins to flash slowly. ...
seconds, then stop and continue to monitor all protected entry points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed and ignore that triggered zone. Whenever the system is armed, the dash mounted LED indicator will slowly flash.
Headlight Illumination - Optional Illuminated Entry Upon Disarm SILENT DISARMING 1. As you approach the vehicle, press and hold the Unlock button on the keychain transmitter for 2 seconds. Dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is rearming automatically.
If the LED is flashing one time...pause...one time...pause...etc., then an intrusion attempt was made to the shock sensor, or an accessory triggering device that may have been added to the system. If the LED is flashing two times...pause...two times...pause...etc., then an intrusion attempt was made to a hood or trunk pin switch that was added to the system, or to a light activated entry point if the alarm was installed using the voltage sensing feature.
3. Within 5 seconds, press and release the PBLED override switch. The alarm system will stop sounding and enter the (bypassed) mode. You can now start and operate the vehicle normally. Typically this override mode is used only if the transmitter has become inoperative.
Page 9
Custom Code Programming Example: To Change the code from the factory pre-assigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.
MANUALLY OVERRIDING YOUR SYSTEM: USING THE CUSTOM CODE OVERRIDE Assuming the override code programmed has not been changed, and the default override code of 11 is in the system's memory. 1. Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.
REMOTE PANIC OPERATION The ARM or DISARM button on your keychain transmitter also functions as a panic switch for use in emergency situations. To use remote panic: 1. Press and hold the ARM or DISARM button on the keychain transmitter for 3 or more seconds.
Page 12
ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 ) This security system has an additional feature that can be connected to a number of different optional accessories. Some of the more common uses for this channel are: Remote Trunk Release Remote Car Starter ...
IGNITION CONTROLLED LOCK UNLOCK: (Unlock Drivers, or All Doors) Your security system has a selectable safety feature that allows the vehicle doors to lock when the ignition switch is turned on, (providing all doors are closed), and to unlock the doors when the ignition switch is turned off. In addition, the unlocking of the doors is further selectable, in a two step unlock configura- tion, to unlock only the drivers door or all doors.
PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1) Transmitter Model Name Is Found On Back Of Transmitter Case 1. Turn the ignition key to the on position. 2. Press and release the valet/programming switch 3 times (Siren Chirps). 3. Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren.
