3 Button Remote Security System with Starter Disable
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need to
manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such situa-
tions. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected. Valet
Switch manual override is pre-selected from the factory, however, the system can be
configured for "Custom Code" operation. Confirm the override mode selected on the last page
of this manual and familiarize yourself with the section on it's operation.
FEATURES :
 2 Three Button Programmable RF Transmitters
 Separate Lock/Unlock Transmitter Buttons
 Five Channel Receiver (capable of accepting 4 transmitters)
 Code Hopping Technology
 Selectable Manual Override Mode
 Remote Panic in all modes (Improved)
 Protected Valet
 User Programmable Manual Override Code
 7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
 Intrusion Alert with Memory
 Audible Arm / Disarm / Defective Zone / Tamper Confirmation
 True Last Door Arming ( hardwire only )
 Defective Zone By-Pass
 Hardwire or Voltage Sense Selectable
 Active or Passive Arming Selectable
 Smart Disarming
 Programmable Auto Lock On / Off
 Programmable Auto Unlock On / Off
 Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
 Programmable Active or Passive Door Locks
 User Programmable Permanent Chirp Delete
 On Command RF Chirp Delete from Transmitter Or Selectable Through Software
 Car Horn Activation for alarm response
 Additional Negative Trigger Input
 RF Inhibit with ignition on
 Parking Light Flasher
OPTIONS:
 6 Tone Multi-Tone Siren
 Remote Trunk Release ( must have electronic trunk release )
 Remote Keyless Entry ( must have power door locks )
 Illuminated Entry
 Multiple Vehicle Capable
 Headlight Illumination during Arming and or Disarming
 Remote Starter
 Remote Power Window Roll Up
 Remote Garage Door Interface
 Plug In Electronic Shock Sensor
Interior Illumination Upon Disarm
Model PRO 9644i
Owner's Manual
Page 1
128-8699
1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiovox Pursuit Series

  • Page 1 Model PRO 9644i Owner’s Manual 3 Button Remote Security System with Starter Disable IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.
  • Page 2: Your " Code Hopping " Transmitters

    YOUR " CODE HOPPING " TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re-transmit at a later time to disarm your system.
  • Page 3: Arming The System - Passive ( Automatic )

    2. Press and hold the Lock button on the keychain transmitter for 2 seconds.  Red dash mounted LED begins to flash slowly.  Parking Lights flash one time.  Siren will not sound. If the siren "chirped" three times, sometime after arming, the exclusive delayed dome light learn circuit has been programmed and the system detected a open entry point after the learned delay expired.
  • Page 4: Disarming The System

    bulb, and will not cause the vehicle’s battery to drain, even when left unattended for extended periods.  Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30 second alarm cycle, attracting visual attention to the vehicle. ...
  • Page 5: Silent Disarming

     Courtesy Lights - Optional Interior courtesy lights turn on for 30 seconds, or until the ignition key is switched on. SILENT DISARMING 1. As you approach the vehicle, press and hold the Unlock button on the keychain transmitter for 2 seconds. ...
  • Page 6: Intrusion Warning Signals

    INTRUSION WARNING SIGNALS This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the parking lights will flash 3 times when disarming the system. Enter the vehicle, and observe the red dash mounted LED to identify which zone was triggered.
  • Page 7 Option. Consult your installation center for programming details. The system comes from the factory with a pre-programmed override code of 11. To change this default override code, do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence.
  • Page 8: Eliminating The Normal Arm/Disarm Chirps

    MANUALLY OVERRIDING YOUR SYSTEM: USING THE CUSTOM CODE OVERRIDE Assuming the override code programmed has not been changed, and the default override code of 11 is in the system's memory. 1) Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.
  • Page 9  Remote Electric Trunk Release  Remote Car Starter  Remote Window Closure  Remote Garage Door Interface NOTE: In addition there may be a second optional feature connected to your system that when the same transmitter button is pressed and released 2 times within 3 seconds (double pressed), the second optional feature will activate.
  • Page 10 PRO 9644i SYSTEM FUNCTIONS AT A GLANCE DASH LED INDICATORS RAPID FLASHING = PASSIVE ARMING SLOW FLASHING = ARMED DISARMED ON SOLID VALET MODE 3 FLASH...PAUSE = INTRUSION ZONE 3 2 FLASH...PAUSE = INTRUSION ZONE 2 1 FLASH...PAUSE = INTRUSION ZONE 1 SIREN AND / OR HORN CHIRP INDICATORS 1 CHIRP * 2 CHIRPS *...
  • Page 11 THIS PAGE LEFT BLANK INTENTIONALLY Page 11 128-8699 11 of 12...
  • Page 12 © 2009 Audiovox Electronics Corporation, Hauppauge, N.Y. 11788 128-8699 Page 12 128-8699 12 of 12...
