The PRO-9600 is a full featured security system with on board paging technology that provides
you with a direct link to your vehicle from anywhere in the world. In addition to operating the
system from your keychain transmitter, this patent pending technology allows you to operate
the vehicle from any land or mobile telephone. You can command the security system to arm
or disarm, release the trunk, start the vehicle, and in case of a carjacking, put the PRO-9600 in
a special carjack mode that will flash the lights, sound the siren and prevent restarting of the
vehicle.
The PRO-9600 can be operated from a telephone by placing a call to the 1-800 number listed
on the wallet card enclosed. The voice prompt interface will request your subscriber # and Pin
#. Then enter the numerical reference # for the command you want to send. The command will
be sent through the satellite and land based network and within minutes your vehicle will re-
spond. It is advised that you read this manual in it's entirety to understand all the features and
options available to your vehicle.
FEATURES:
2 Three Button RF Transmitters
Anti Code Grabbing Technology
Four Channel Receiver
Remote Panic In All Modes
Protected Valet
User Programmable Manual Override
7 Function LED
Intrusion Alert With Memory
Audible Arm, Disarm, Tamper, and Defective Zone Siren Confirmation
Instant Siren Activation
Starter Disable
Additional Engine Immobilizer Circuit (Optional Relay Required)
True Last Door Arming
Active Or Passive Arming Selectable
Programmable Auto Lock
Programmable Auto Unlock
Programmable Door Lock Output Duration
On Command Chirp Delete
User Selectable Permanent Chirp Delete
6 Tone Multi Tone Siren
Car Horn Activation For Additional Alarm Response
RF Inhibit With Ignition On
Dual Light Flash Output
Plug In Two Stage Shock Sensor
Over The Air Vehicle Access Of Channel 2 Auxiliary 1
Over The Air Vehicle Access Of Channel 3 Auxiliary 2
Over The Air Vehicle Access Of Channel 4 Auxiliary 3
Over The Air Vehicle Access Of Vehicle Theft / Hijack Sequence
AVAILABLE OPTIONS:
Remote Trunk Release (Must have power trunk)
Remote Keyless Entry (Must have power locks)
Illuminated Entry
Multi Vehicle Operation
Remote Start
Remote Power Window Control (Must have power windows)
Remote Garage Door Control (Must have electric garage door)
Model PRO-9600
Owner's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit PRO-9600 and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox Pursuit PRO-9600

Summary of Contents for Audiovox Pursuit PRO-9600

  • Page 1 The PRO-9600 is a full featured security system with on board paging technology that provides you with a direct link to your vehicle from anywhere in the world. In addition to operating the system from your keychain transmitter, this patent pending technology allows you to operate the vehicle from any land or mobile telephone.
  • Page 2 Your PRO-9600 Remote Security System with on-board Satellite/Paging Access has many features and available options; some of which are selected at time of installation. For your reference, the list on the back page of this manual shows what features and options have been installed.

  • Page 3: Protection While The System Is Armed

    point is opened during the 30 second arming cycle, arming will be suspended. When all entry points are closed, the arming cycle will begin again. At the end of the 30 seconds, The parking lights will flash once, the siren will chirp once, and the dash mounted LED will begin to flash slowly confirming the system is armed.

  • Page 4: Silent Disarming

    SILENT DISARMING: As you approach the vehicle, press and hold the arm/disarm button of your key chain trans- mitter for two seconds. The parking lights will flash twice, and the dash mounted LED will turn off confirming that the system is disarmed. If you have the optional door lock/unlock circuit installed, the doors will unlock.
  • Page 5 PROGRAMMING YOUR MANUAL OVERRIDE CODE: Your security system can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to disarm the system if you lose your transmitter, or if the transmitter battery fails. In order to provide the highest level of security, this system will allow you to program your personal manual override code.

  • Page 6: Eliminating The Normal Arm/Disarm Chirps

    3. As soon as the chirp that corresponds to your first digit sounds, quickly turn the ignition key; a) Off then on if your second digit is 1 b) Off then on, then off, then on if your second digit is 2. c) Off then on, off then on, off then on, if your second digit is 3.
  • Page 7 The configuration listed indicates the default setting from the factory. If the installation of your unit specifies a different transmitter configuration, the transmitter operation will be listed on the rear page of this manual. REMOTE CHANNEL 2 / AUXILIARY 1 FUNCTIONS: This security system has an additional feature that can be connected to a number of optional accessories.
  • Page 8 3. Unlocking of the vehicle Doors; (Must have power door locks and optional interface in- stalled). If you've ever locked your keys in your vehicle, this command requires no expla- nation. A simple phone call to the 1-800 number and you're in. 4.

  • Page 9: System Functions At A Glance

    SYSTEM FUNCTIONS AT A GLANCE DASH L.E.D. INDICATION: RAPID FLASHING SLOW FLASHING ON SOLID 3 FLASH...PAUSE 2 FLASH...PAUSE 1 FLASH...PAUSE SIREN AND OR HORN CHIRP INDICATION: 1 CHIRP 2 CHIRPS 3 CHIRPS 4 CHIRPS 3 SHORT, 3 LONG, 3 SHORT CHIRPS... = **These Chirps are optional and may be selected off.

  • Page 10: Product Information

    Your PRO-9600 (Patent Pending), Satellite/Pager Based Remote Security System provides a direct link between you and your vehicle from virtually any phone in the world. You can command your vehicle to activate any of the installed options including unlocking the doors, arming or disarming the system, opening the trunk, auto locate or carjack/theft (Flash the lights, sound the horn, interrupt the starter.) The following options have been installed in your vehicle:...
