3 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
FEATURES:
2 Three Button Programmable RF Transmitters
Three Channel Code Learning Receiver
Anti Code Grabbing Technology
Remote Panic In All Modes
Protected Valet/Override
Remote Start Safety Control Switch
Safe Start RF Control (Double Push Of RF Transmitter)
Selectable Automatic Timed Start Mode
7 Function LED, Arming, Armed, Disarmed, Valet, Zones 1, 2, & 3
Intrusion Alert With Memory
Audible Arm, Disarm, Defect Zone, And Intrusion Indications
Instant Siren Activation All Entry Points
Starter Disable When Armed
True Last Door Arming
Defective ZoneBy-Pass
On Command RF Chirp Delete
Six Tone Siren
Two Stage Shock Sensor
Selectable Run Time 10 or 15 Minutes
OPTIONS:
Remote Trunk Release
Remote Keyless Entry
Illuminated entry
Remote Power Window Control
Remote Garage Door Interface
Multiple Vehicle Capable
CAUTION! Be certain that the vehicle is outdoors before using this or any
remote vehicle starting device. A running engine produces dangerous
carbon monoxide fumes which can be harmful or fatal if prolonged
exposure occurs. DO NOT remote start the vehicle if it is garaged.
Released 8-20-98
Model PRO-9675FT
Owner's Manual
Page 1
128-5370
1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox PRO9675FT4
Summary of Contents for Audiovox PRO9675FT4
- Page 1 3 Button Remote Start Security System With Plug-In Shock Sensor & Starter Disable FEATURES: 2 Three Button Programmable RF Transmitters Three Channel Code Learning Receiver Anti Code Grabbing Technology Remote Panic In All Modes Protected Valet/Override Remote Start Safety Control Switch Safe Start RF Control (Double Push Of RF Transmitter) Selectable Automatic Timed Start Mode 7 Function LED, Arming, Armed, Disarmed, Valet, Zones 1, 2, &...
- Page 2 Your PRO-9675FT Remote Start Alarm System has many features and available options some of which are selected at time of installation. For your reference, the list on page 7 of this manual shows what features and options have been installed. Consult your installing dealer for options that may have been installed and are not listed.
- Page 3 At the end of the 30 seconds, the parking lights will flash once, the siren will chirp once, and the dash mounted LED will begin to flash slowly confirming the system is armed. If the siren did not sound when arming, then the chirps have been turned off. Refer to the section on "Eliminating the Arm/Disarm Chirps"...
- Page 4 Note: If the passive arming mode was selected at time of installation, the dash mounted LED will start flashing rapidly indicating that the system is rearming. Opening any door will suspend the automatic arming. If the parking lights flashed three times, and the siren chirps four times, this indicates that the alarm system had been triggered in your absence.
- Page 5 2. Turn the ignition switch 'on" then 'off'. 3. Within 10 seconds of turning off the ignition, move the valet switch "on", "off", "on", "off", "on", "off". 4. If the chirps were on before you started, the siren will emit 2 short chirps indicating that the chirps are now off.
- Page 6 indication, the parking lights will flash or turn on depending on the programming set up by your installation center. When you arrive at your vehicle, disarm the alarm system by pressing and releasing the arm/disarm button of your keychain transmitter. Enter the vehicle and turn the ignition key to the on position.
- Page 7 ADDITIONAL REMOTE FUNCTION CHANNEL 2 The system has an additional feature, ( Channel 2) ,that can be connected to a number of different optional accessories. Some of the more common uses for this channel are: Remote Trunk Release Remote Window Close Remote Garage Door Interface To operate the accessory associated with channel 2, press and hold the icon of your keychain transmitter shown...
- Page 8 2 FLASH 3 FLASH CONTINUOUS FLASH REMOTE START SIREN INDICATIONS 1 LONG/1SHORT REMOTE START PARKING LAMP INDICATIONS 1 FLASH CONTINUOUS FLASH Audiovox Corp., Hauppauge, N.Y. 11788 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2 INTRUSION ZONE 1...
