Note : When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin switch in order to
begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
1 Sec.
2nd Accy Lock
Auto Lock On
3rd Accy. UL
Auto UL Dr.
4th Passive Locks
Passive
5th Passive/Active Arm
Passive Arm
6th Voltage Sense
Voltage Sense
7th Siren/Horn
Siren/Horn
8th Horn Chirp
10mS
9th Override Method
Custom Code
10th Two Step Unlock
On
11th Chirp Delete From Tx
On
To program these selectable features;
Turn ignition on No response
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Second
Press and release the valet switch
Press transmitter Lock button to change
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Fifth
Press and release the valet switch
Press transmitter Lock button to change
Sixth
Press and release the valet switch
Press transmitter Lock button to change
Seventh
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter lock button to change
Sixth
Press and release the valet switch
Press transmitter Lock button to change
Seventh
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter lock button to change
1 Chirp
2 Chirps
3.5 Sec.
Auto Lock Off
Auto UL All
Active
Active Arm
Hardwire
Siren Only
16mS
Valet
Off
Off
Action
o r
o r
o r
o r
o r
o r
o r
Model PRO-9642CH
Installation Manual
3 Chirps
4 Chirps
1 Sec L, Dbl. U/L
Auto UL Off
Horn Only
30mS
System Response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock dr.
2 chirps = auto unlock all
2 chirps = active locks
1 chirp = passive locks
2 chirps = active arming
1 chirp = passive arming
2 chirps = hardwire
1 chirp = voltage sense
1 chirp = siren and horn output
2 chirps = siren output only
3 chirps = horn output only
2 chirps = hardwire
1 chirp = voltage sense
1 chirp = siren and horn output
2 chirps = siren output only
3 chirps = horn output only
Default
1 Sec.
Auto Lock Off
Auto UL Off
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
Off
128-6623
1 of 8
