3 Button Remote Security System
FEATURES:
w 2 Three Button Programmable RF Transmitters
w Three Channel Receiver (capable of accepting 4 transmitters)
w Code Hopping Technology
w Remote Panic in all modes
w Protected Valet
w 7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
w Intrusion Alert with Memory
w Audible Arm / Disarm / Defective Zone / Tamper Confirmation
w Instant Siren Activation
w Low Current Horn Output
w Starter Disable
w True Last Door Arming (hardwire only)
w Defective Zone By-Pass
w Hardwire or Voltage Sense Selectable
w Active or Passive Arming Selectable
w Programmable Auto Lock On / Off
w Programmable Auto Unlock On / Off
w Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
w Programmable Active or Passive Door Locks
w User Programmable Permanent Chirp Delete
w On Command RF Chirp Delete from Transmitter
w 6 Tone Multi-Tone Siren
w RF Inhibit with ignition on
w Parking Light Flasher
OPTIONS:
w Single or Dual Stage Shock Sensor
w Remote Trunk Release
w Remote Keyless Entry
w Multiple Vehicle Capable
w Remote Starter
w Remote Power Window Roll Up
w Remote Garage Door Interface
Model PRO-9642CH
Owner's Manual
128-6622
1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit PRO-9642CH and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiovox Pursuit PRO-9642CH

  • Page 1 3 Button Remote Security System FEATURES: w 2 Three Button Programmable RF Transmitters w Three Channel Receiver (capable of accepting 4 transmitters) w Code Hopping Technology w Remote Panic in all modes w Protected Valet w 7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming w Intrusion Alert with Memory w Audible Arm / Disarm / Defective Zone / Tamper Confirmation w Instant Siren Activation...
  • Page 2: Arming The System - Active

    NOTE: Your system has the option of using a siren, the vehicle horn, or both for the sounding device. Where the siren is referenced below, the horn or both may in fact chirp, or beep. ARMING THE SYSTEM - ACTIVE 1.
  • Page 3: Protection While The System Is Armed

    o Doors Lock - Optional Door locking during passive arming is a selectable feature. The alarm can be programmed to allow the doors to lock only when arming using the keychain transmitter and they will not automatically lock during passive arm- ing.
  • Page 4: Silent Disarming

    SILENT DISARMING 1. As you approach the vehicle, press and hold the Disarm / Unlock button on the keychain transmitter for 2 seconds. þ Red dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is re-arming automatically.
  • Page 5: Manually Overriding Your System

    hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions are bypassed, however the remote panic feature and remote door locks will remain operational. To use the valet mode, the system must first be disarmed either by using your keychain transmitter or by overriding the system, then: 1.
  • Page 6 If the new code was accepted, the unit will report back the newly entered code, by flashing the LED, first indicating the 10ths digit, pause and then the units digit. The unit will report the new code three times with a one second pause between each code, then the system will begin arming.
  • Page 7: Eliminating The Normal Arm / Disarm Chirps

    NOTE: If the siren/horn chirps two times, regardless of the valet switch operation as described above, then the horn and siren chirps have been turned off via programming features 7 and 8. Contact your installation center or Audiovox technical department for information on how to reinstate the chirp feature through programming.
  • Page 8: System Functions At A Glance

    Auto Unlock with ignition key o Passive Arming o No Lock in passive mode o Hardwire doors, hood, and trunk o Siren Activation o Horn Activation © 2003 Audiovox Electronics Corporation, Hauppauge N.Y. 11788 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3...
